Interface: Ethernet Technology:
2.5 Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
PoE (RJ-45) Port:
Yes
PoE PD Port:
Yes
Part Number: NWA90AXPRO
Antenna: Antenna Form Factor:
Internal
Certifications: Certifications & Standards:
FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893
LP0002
EN 60601-1-2
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55022
EN55024
EN61000-3-2/ -3
BSMI CNS13438
EN 60950-1
IEC 60950-1
BSMI CNS14336-1
Wireless Data Rates: 5 GHz: Up to 867 Mbps
2.4 GHz: Up to 300 Mbps
Frequency Band: 2.4 GHz / 5 GHz
Interface: Uplink port: One 10/100/1000 Mbps Ethernet Port, accepts 802.3af or 802.3at PoE
Access ports: Three 10/100/1000 Mbps Ethernet Ports with one PoE power pass-thru port
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Interface: 1 x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication§
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Interface: 1 x 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Interface: 1 x PoE+ Gigabit LAN port (power input)
1 x Gigabit LAN port
Power port (optional non-PoE installation)
LED indicators
Mounting plate and cable guard
On/Off power button
Reset button
Standards: IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3at
IEEE 802.1Q
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (up to 400 Mbps @ 256 QAM)
IEEE 802.11ac Wave 2 (5 GHz 1: up to 867 Mbps, 5 GHz 2: up to 867 Mbps @ 256 QAM)
