Interface: 1 x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication§
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Frequency Band: Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Antenna: Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN Ports: Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot...
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Wireless Data Rates: 802.11b: 1, 2, 5.5, and 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz and 5GHz: 6.5 to 600Mbps (only 20 MHz and MCS 0 to MCS 15)
802.11ac data rates (5 GHz): 6.5 to 1733Mbps (MCS0-MCS9)
Interface: 2 x Gigabit (10/100/1000BASE-T autosensing), Power over Ethernet (PoE)
RJ-45 console port (not functional)
USB 2.0 (not functional)
Interface: 1 x 2.5 Gbps Ethernet Port (supports IEEE802.3at PoE)
Standards: IEEE 802.11ax/ac/n/g/b/a
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Interface: 1 x Gigabit Ethernet (RJ-45) Port (Support IEEE 802.3af PoE and Passive PoE)
Standards: IEEE 802.11ac, IEEE 802.11a/b/g/n
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
Interface: 1 x 10/100 Mbps Shielded Ethernet Port (Passive PoE in)
1 x Grounding Terminal
1 x Reset Button
PoE Adapter:
1 x AC Jack with Ground
1 x 10/100/1000Mbps Shielded Ethernet Port (Power + Data)
