D-Link DGS-1100-24P Smart 24P Gigabit EasySmart Switch

Be the first to review this product...
  • 8K MAC Address Table
  • 3.5Mbits Buffer Memory
  • Smart
Specs
Reviews

Learn more about the D-Link DGS-1100-24P

Model
Brand D-Link
Model DGS-1100-24P
Format & Standards
Format Rackmount
Standards IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management Type Smart
Ports & Interface
Uplink Ports None
Primary Ports 24 x RJ45
Primary Port Speed 10/100/1000Mbps
Data Transmission
MAC Address Table 8K
Switching Method Store and Forward
VLAN Support Port-based
802.1Q Tagged VLAN
VLAN Group
- Supports 32 static VLAN groups
- Max. 4094 VIDs
Surveillance VLAN
Buffer Memory 3.5Mbits
Details
PoE No
Stackable No
QoS No
Layer Layer 2 Only
LEDs Power (Per Device)
Link/Activity/Speed (Per Port)
Power Supply
Power 100 to 240 VAC, 50 to 60 Hz Internal Universal Power Supply.

Power Consumption: 14.83 watts.
Dimensions & Weight
Dimensions 11" x 7.1" x 1.73"
Weight 3.5 lbs.
Environmental
Temperature 0°C to 40°C (32°F to 104°F)
Humidity 10% - 95%, Non-condensing
Features
Features Switching Capacity: 48 Gbps

Max. Forwarding Rate: 35.71 Mpps

Packet Baffer: 3.5 Mbits

Flash Memory: 2 MB

EMI: FCC Class A, CE Class A, VCCI Class A, ICES-003, C-Tick

Safety: cUL, CE LVD

L2 Features:
MAC Address Table: 8k
Flow Control
- 802.3x Flow Control
- HOL Blocking Prevention
IGMP Snooping
- IGMP v1/v2 Snooping
- Supports 32 Groups
Loopback Detection
Static Trunk
- 8 groups, 2-4 ports per group
Port Mirroring
- One-to-One
- Many-to-One
Cable Diagnostics Statistics
- Tx Ok
- Tx Error
- Rx Ok
- Rx Error.

D-Link Green: Compliance with IEEE 802.3 oz Energy Efficient Ethernet

RFC Standard List:
RFC 768 UDP
RFC 791 IP
RFC 792 ICMP
RFC 793 TCP
RFC 826 ARP
RFC 951 BootP Client
RFC 1542 BootP/DHCP client
RFC 1945 HTTP/1.0
RFC 2647 802.1p.
Additional Information
First Listed on Newegg June 02, 2015

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): Lifetime
  • Limited Warranty period (labor): Lifetime
