Main image of TRENDnet 12-Port Gigabit PoE+ Smart Surveillance Switch, TPE-3012LS, 8 x Gigabit PoE+ Ports, 2 x Gigabit Ports, 2 x SFP Slots, 110W PoE Budget, Managed Switch, Long Range PoE+ up to 200m (656 ft)

Alt view image 2 of 3 - TRENDnet 12-Port Gigabit PoE+ Smart Surveillance Switch, TPE-3012LS, 8 x Gigabit PoE+ Ports, 2 x Gigabit Ports, 2 x SFP Slots, 110W PoE Budget, Managed Switch, Long Range PoE+ up to 200m (656 ft)

Alt view image 3 of 3 - TRENDnet 12-Port Gigabit PoE+ Smart Surveillance Switch, TPE-3012LS, 8 x Gigabit PoE+ Ports, 2 x Gigabit Ports, 2 x SFP Slots, 110W PoE Budget, Managed Switch, Long Range PoE+ up to 200m (656 ft)

Shop All TRENDnet Products | Visit OneDealOutlet Canada Store

TRENDnet 12-Port Gigabit PoE+ Smart Surveillance Switch, TPE-3012LS, 8 x Gigabit PoE+ Ports, 2 x Gigabit Ports, 2 x SFP Slots, 110W PoE Budget, Managed Switch, Long Range PoE+ up to 200m (656 ft)

Be the first to review this product...

8 x Gigabit PoE+ ports, 2 x Gigabit ports, 2 x SFP slots
110W PoE power budget, Easy-to-use web-based management interface
Supports IPv6, LACP, VLAN, QoS, and IGMP Snooping
Extend PoE+ signal up to 656 ft./200m at 10Mbps
Front panel 4-digit LED display provides PoE power statistics
Surveillance mode GUI for simplified configuration and network monitoring
Device discovery for ONVIF compliant IP cameras and NVRs
Upload building floorplans to create an E-map of surveillance devices
Change IP camera IP address settings, Upgrade IP camera firmware
Change IP camera administrator user name and password, Bandwidth control per port
802.1Q, MAC, Surveillance, and Voice VLAN support
IEEE 802.1p QoS with queue scheduling support, 24Gbps switching capacity
IEEE 802.1p QoS with queue scheduling support

Overview

Specs

Reviews

TRENDnet's Gigabit PoE+ Smart Surveillance Switch series is designed to simplify the installation and management of surveillance networks, especially for integrators and installers. These ONVIF switches are optimized for the surveillance industry; surveillance mode provides a graphical dashboard interface with detailed information about the switch and each connected PoE device. Connect ONVIF compliant IP cameras and NVRs for more advanced capabilities such as changing device IP settings, and to view individual IP camera video within the switch GUI. The Smart Surveillance Switches are also PoE self-healing switches featuring PoE device auto-recovery and power scheduling.

Model
Brand	TRENDnet
Model	TPE-3012LS (V1.0R)

Format & Standards
Format	Desktop
Standards	IEEE 802.1d IEEE 802.1p IEEE 802.1Q IEEE 802.1s IEEE 802.1w IEEE 802.1X IEEE 802.1ab IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3z IEEE 802.3ab IEEE 802.3ad IEEE 802.3af IEEE 802.3at IEEE 802.3az
Network Management Type	Smart

Ports & Interface
Primary Ports	10 x RJ45 + 2 x SFP
Primary Port Speed	10/100/1000Mbps

Data Transmission
MAC Address Table	8K
Switching Method	Store and Forward
VLAN Support	Multiple management VLAN assignment 802.1Q Tagged VLAN MAC-based VLAN Surveillance VLAN Voice VLAN Up to 256 VLAN groups, ID Range 1-4094

Details
Buffer Memory	512KB
PoE	PoE budget: 110W 802.3at: up to 30W per port (ports 1-8) PoE Mode A: Pins 1,2 and pins 3,6 for power PoE power scheduling PD alive check Over current/short circuit protection
SNMP	Yes
QoS	802.1p Class of Service (CoS) DSCP (Differentiated Services Code Point) Bandwidth limit per port Queue Scheduling: strict priority (SP), weighted round robin (WRR)
LACP	Yes
Port Mirroring	Yes
Power	Input: 100 - 240V AC, 50/60Hz, internal power supply Max. consumption: 10W (No PoE load)

Features
Features	8 x Gigabit PoE+ ports 2 x Gigabit ports 2 x SFP slots 110W PoE power budget Easy-to-use web-based management interface Supports IPv6, LACP, VLAN, QoS, and IGMP Snooping Extend PoE+ signal up to 656 ft./200m at 10Mbps Front panel 4-digit LED display provides PoE power statistics Surveillance mode GUI for simplified configuration and network monitoring Device discovery for ONVIF compliant IP cameras and NVRs Upload building floorplans to create an E-map of surveillance devices Change IP camera IP address settings Upgrade IP camera firmware Change IP camera administrator user name and password Bandwidth control per port 802.1Q, MAC, Surveillance, and Voice VLAN support IEEE 802.1p QoS with queue scheduling support 24Gbps switching capacity IEEE 802.1p QoS with queue scheduling support

Dimensions & Weight
Dimensions	12.90" x 9.10" x 1.75"
Weight	4.98 lbs.

Environmental
Temperature	Operating Temperature 0° - 40° C (32° - 104° F)
Humidity	Operating Humidity Max. 90% non-condensing

Packaging
Package Contents	TPE-3012LS Quick Installation Guide Power cord (1.5m/5 ft.) Rackmount kit
