Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: Genesys Logic - GL3523 (USB Hub), Realtek - RTL8153 (LAN), Parade Technologies - PS176 (HDMI)
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type: 1 - USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.10 to 10.12 / Chrome OS
Note:
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt mode.
A 4K-capable display is required to achieve 4K x 2...
Specifications: System Requirements:
Computer with USB-C port that supports USB DisplayPort Alternate Mode
DisplayPort, Mini DisplayPort, VGA, DVI or HDMI external display
Ethernet network
Thunderbolt 3: Yes
Package Contents: U442-DOCK1 USB 3.1 Gen 1 USB-C Docking Station
Owner’s manual
Ports Spec: 2 x USB Type-C (24 pin) USB 3.0 Female
2 x HDMI (19 pin) Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
Compatibility: Windows 11; Windows 10; MacOS; Chrome
Ports Spec: Top components: LED and power button to power or wake host system Front components: 1 x USB-C data/power out, (USB 3.2 Gen 2 10 Gbps Data only) Side components: Right side: 1 x Kensington Standard Lock Slot; 2 x USB 3.2 Gen 1 ports - 1 on each side (charging)
Compatibility: OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 - 10.12, 10.14
Chrome OS v55+
Ports Spec: 1 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
1 x USB Type-C (24 pin) USB 3.0 Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x Ethernet Gigabit Female
1 x 3.5 mm Mini-Jack (4 Position) Female
1 x SD / MMC Slot Female
Compatibility: Software
OS Compatibility Windows 7, 8, 8.1, 10
Mac OS 10.11 to 10.12
Ports Spec: 2 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
2 x USB Type-C (24 pin) USB 3.0 Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
2 x 3.5 mm Mini-Jack (3 Position) Female
1 x Security Lock Slot Female
Compatibility: OS Compatibility
Windows 7, 8, 8.1, 10
macOS 10.9 - 10.12, 10.14
Chrome OS v55+
Ports Spec: 2 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
2 x USB Type-C (24 pin) USB 3.0 (5Gbps) Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
2 x 3.5 mm Mini-Jack (3 Position) Female
1 x Security Lock Slot Female
Specifications: Connector A: USB C (MALE)
Connector B: HDMI (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Package Contents: U444-06N-HD-AM USB 3.1 Gen 1 to HDMI Alternate Mode Dual/Multi-Monitor External Video Graphics Card Adapter
Quick Start Guide
