Specifications: Cable Management: Yes
Mounting Options: Desk & Grommet Clamp
VESA Hole Pattern(s): 75x75 mm / 100x100 mm
Display Rotation: 360°
Display Tilt: + 30° / - 30°
Dual-Arm Span: 32.87" (835 mm)
Height Adjustment: Yes
Maximum Display Size: 27in
Maximum Height: 14.3 in [364 mm]
Minimum Display Size: 13"
Pole Height: 14.2" (360 mm)
Swivel / Pivot: +30°/ -30°
Features: Save space by mounting two monitors 13" to 27" onto a single low-profile base with this desk-mount dual monitor arm
Desk-clamp or grommet-hole monitor mount
Double monitor mount with adjustable height along the pole
Adjust for optimum viewing with +/- 30° tilt and +/- 30° swivel
Micro-adjustment feature lets you perfectly align your monitors
Place monitors close to a wall or cubicle wall with a low-profile design
Dual screen mount su...
Specifications: Supports monitors up to 22 lbs (10 kgs.)
Screen size: 13" to 27"
Tilt angle: +/-15 degrees
Swivel: 360 degrees
Rotation: 360 degrees
Height adjustment: Up to 18"
Dual articulating mounting arms extend up to 16.5"
Compatible with VESA mounting 75x75mm and 100x100mm patterns
Product dimensions: 3.95" (W) x 25" (H) x 35.45" (D)
Product weight: 10.6 lbs
Color: Black
Specifications: # of displays supported: 2
Mounting Options: Stand
One-touch height adjustment: No
VESA Hole Pattern(s)
75x75 mm
100x100 mm
Wallmountable: No
Height Adjustment: Yes
Maximum Display Size: 24in
Maximum Height Extension: 16 in [406.4 mm]
Swivel / Pivot : 360° at each display
Tilt: +/-15
Weight Capacity: 282.4 oz [8000 g]
Specifications: Supports two displays between 15.00" - 24.00" with maximum weight 26.00 lbs. per display
Flexibility to tilt up and down +/- 20 degree
Swivel displays side to side +/- 20 degree
Rotate 90 degree for landscape or portrait mode
Hole pitch 100 mm x 100 mm VESA and 75.00 mm x 75.00 mm VESA
Specifications: Compatibility: 75mm x 75mm and 100mm x 100mm VESA patterns, and screens from 13" - 27"
Weight capacity: 17.6 lbs per arm
Height Adjustable: Up to 17"
Screen Orientation: Portrait or landscape
Tilt: +/-80 degrees
Swivel: 360 degrees
Materials: Heavy-duty steel, black powder coat finish
Specifications: Maximum Screen Size Supported: 32"
VESA Mount Standard: 75 x 75, 100 x 100
Number of Displays Supported: 2
Material Steel: Aluminum
Adjustable Height: Yes
Specifications: # of Displays Supported: 1
Articulating: No
Cable Management: Yes
Mounting Options: Wall-Mount
VESA Hole Pattern(s): 75x75 mm / 100x100 mm
Display Pan: +180° / -180°
Display Rotation: 360°
Display Tilt: +90° / -15°
Height Adjustment: No
Maximum Arm Extension: 20.5 in [520 mm]
Maximum Display Size: 30in
Minimum Display Size: 13"
Weight Capacity (Per Display): 30.9 lb [14 kg]
Swivel / Pivot:
+180°/-180° at the wall
360° at the shoulder
360° at the elbow
Included in Package:
1 x Wall Mount
2 x Swivel Arms
1 x Monitor Mount
4 x Thumb Screws
1 x M3 Hex Key
2 x Wall Plugs
2 x Mounting Screws
1 x User Manual
Specifications: Color: Black
Construction Material: Aluminum
# of Displays Supported: 2
Articulating: Yes
Mounting Options: Desk Clamp
Mounting Surface Thickness: Desk Clamp: Table Thickness 0.39 - 3.46 in. (10 - 88 mm)
VESA Hole Pattern(s): 75x75 mm / 100x100 mm
Wallmountable: No
Display Rotation: 360°
Display Swivel: +90° / - 90°
Display Tilt: + 30° / - 30°
Height Adjustment: Yes
Maximum Arm Extension: 15.2 in [386 mm]
Maximum Display Size: 32in
Swivel / Pivot: +/- 90° around the support post
+/- 180° at the shoulder
+/- 90° at the elbow
Weight Capacity (Per Display): 17.7 lb [8 kg]
Included in Package:
1 x Desk Clamp Assembly, Lower
1 x Desk Clamp Assembly, Upper
1 x Swivel Arm Assembly
1 x Pole
2 x Desk Clamp Screws
3 x Pole Assembly Screws
1 x 4mm Hex Key
1 x 6mm Hex Key
8 x M4 x 12 mm Screws
8 x M5 x 12 mm Screws...
Features: 1 x Desk Clamp, Lower
1 x Pole Assembly
1 x Pole Cap
2 x VESA Mount
2 x VESA Plate
2 x Support Collar
8 x M4x10mm Screws
8 x M4x16mm Screws
8 x 3/8"x1/2" Screws
8 x Spacers
1 x M6 Hex Key
1 x M3 Hex Key
1 x Wrench
1 x Quick-Start Guide
Specifications: # of displays supported: 2
Mounting Options: Desk Clamp
One-touch height adjustment: Yes
VESA Hole Pattern(s):
75x75 mm
100x100 mm
Display Rotation: 360°
Height Adjustment: Yes
Maximum Arm Extension: 22.3 in [567.5 mm]
Maximum Arm Span: 44.7 in [1135 mm]
Maximum Display Size: 30in
Mounting Surface Thickness: 90 mm (3.54 in.)
Pan: 180°
Swivel / Pivot:
135° around the support post
360° at the elbow
Tilt: +90° / -65°
Weight Capacity: 17.7 lb [8 kg]
Specifications: Max Weight per mount (lbs): 26.5
Mounting Hole Pattern (mm): 75 x 75; 100 x 100
Screen rotation (portrait/landscape): 360°
Tilt/Pan adjustment: Ball joint mechanism allows 20 degrees display adjustment in any direction from the vertical plane
Pole height (inches): 18.7
Cable management: Internal / Integrated
Mounting options: Freestanding
Pole diameter: 1.6
Foot print (inches): 16.6 x 12
Color: Silver with black donuts
Specifications: LCD Size: < 24"
Wt. Capacity: < 25 lbs, 11.3 kg
Tilt: 180°
Rotation: 360° P/L
VESA: MIS-D
Description: Neo-Flex Dual Monitor Wall Mount
Includes two (2) 100 Series Single Pivots, 26" Wall Track, two (2) Track Mount Bracket Kits
Mounting Standards: VESA FDMI, MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Specifications: LCD Size: <= 22"
Weight Capacity: 13 lbs (5.9 kg) per mount, 26 lbs (11.8 kg) total. Note: Monitors must be equal in weight or ±1 pound (.45 kg)
Monitor depth greater than 3" (7.5 cm) may diminish capacity
Install display mounts on the bow at +2.5° or -2.5° angle to optimize viewing conditions
Monitors are installed with 8° inward off-set angle, creating a 16° viewing parabola for better sight lines
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Durable, easy-to-clean powder-coated painted steel exterior
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud
Includes wall mount bracket, 2 extensions, crossbar and 2 sliding LCD mounts, VESA mounting screws
Features: The sturdy construction of this 2-display panel mount supports a great number of advantages for those wanting to create amore ergonomic and functional workspace. SEE MORE and DO MORE with features like: 90 Degree Monitor Rotation, Height Adjustment, Cable Management, Arm Angle Adjustment, IntelliTorque Hinge System, Aluminum Allow Structure, Easy
