Specifications: Chipset ID: JMicron - JMS580
Drive Size: 22mm - M.2 SATA
Supported Drive Height(s): 2242 / 2260 / 2280
Compatible Drive Types: M.2 (SATA, B-Key, NGFF) / M.2 SATA (NGFF, B+M-Key)
Maximum Data Transfer Rate: 6 Gbps
MTBF: 50,000 hours
TRIM Support:Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
Drive Connectors: 1 - M.2 (SATA, B-Key, NGFF) Receptacle
Host Connectors: 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Male
Note:
Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.
Compatibility: OS Compatibility
Windows 7, 8, 8.1, 10
macOS 10.9 - 10.12, 10.14
Chrome OS v55+
Ports Spec: 2 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
2 x USB Type-C (24 pin) USB 3.0 (5Gbps) Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
2 x 3.5 mm Mini-Jack (3 Position) Female
1 x Security Lock Slot Female
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: Genesys Logic - GL3523 (USB Hub), Realtek - RTL8153 (LAN), Parade Technologies - PS176 (HDMI)
Displays Supported: 1
Fast-Charge Port(s): No
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type: 1 - USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8, 8.1, 10 / Mac OS 10.10 to 10.12 / Chrome OS
Note:
Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your laptop USB-C port supports DP alt mode.
A 4K-capable display is required to achieve 4K x 2...
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Connector Detail: Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 1 x DisplayPort (20 pin) Male Output
Note: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Compatibility: Windows 8.1, 10
MacOS 10.10 to 10.15, 11
Ubuntu 18.04, 20.04
Chrome OS
Android 9.0
IPadOS
Ports Spec: 1 - Internal Ports:
USB 3.1 USB Type-A (9 pin, Gen 1, 5 Gbps)
USB 3.0 A (Fast-Charge, 9 pin)
USB Type-C (24 pin) USB 3.0 (5Gbps)
Ethernet Gigabit
HDMI
VGA (14 pin, High Density D-Sub)
1 - Host Connectors:
USB Type-C (24 pin) USB 3.0 (5Gbps)
Specifications: Audio Specifications: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 or 1080p
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions: 1024 x 768, 1280 x 720 (High-definition 720p), 1920 x 1080 (High-definition 1080p), 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160 (Ultra HD 4K)
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
