4 Ports HDMI 2.0 KVM Switch 4K@60Hz USB HDMI KVM Adaptive EDID/HDCP Decryptionfor Mouse Keyboard Hub for PC Laptop (without Remote Controller)

1.Description

HDMI2.0 4 ports KVM switch; 4 groups of high-definition video source and USB interface realize freely switch. Adaptive EDID/HDCP decryption. The equipment has excellent image processing and transmission capacity, make the output signal is more smooth and steady, is a reliable, high performance and efficient way of HDMI USB switch. Suitable for office, computer room, monitoring host,etc.



2.Features

The 4 routes of high-definition video source and USB interface implement freely switch

HDMI 2.0 Compatible input and output ports

Supports video solution up to 4K@60Hz(Total 18Gbps),

Support RGB 4:4:4 /YCbCr 4:4:4 / YCbCr 4:2:2 / YCbCr 4:2:0;

Support Deep Color

Support HDMI input and backward compatibility,allows DVI inputs,

Adaptive EDID/HDCP decryption, able to adapt to a variety of complex application environment;

It can be switched by button mode and Remote control , which is convenient and quick;

HDCP 2.2 standard - high-bandwidth digital content protection technology;

High compatibility, can auto-match source and display device;

Built-in automatic adjustment system, make the image smooth,clear and stable;

Built-in ESD protection system;

Simple to install, plug and play;



Description

Video Standards:HDMI 2.0;HDCP 2.2

Video Maximum data rate:up to 6Gbps per lane(Total 18Gbps)

Resolution range:Up to 3840*2160@60Hz 1920*1080@60Hz

Connector:HDMI-A Interface

HDMI Cable Range <15M(Res:1920*1080@60Hz);<5M (Res:3840*2160@60Hz)

USB Interface protocols:USB2.0

PC input:USB-B(USB-C);Output:USB-A

Power supply USB Power

Power dissipation MAX 4W

Temperature Operating: -5? ~ +70?

Humidity Operating: 5% ~ 90%
