Upstream: 1x USB Type-C connector (connection to the host) Supports DP1.2 Alt Mode, with maximum bandwidth of 5.4Gbps per lane, 4 lanes 21.6Gbps
Downstream: 1x HDMITM socket supports HDMITM max 4K/60Hz 4:4:4 8bit with 18Gbps bandwidth. Supports 6/8/10/12 bit colour depth output. Supports output pixel format RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2. Supports HDCP 2.2 & HDCP1.4. Supports HDR 1x USB Type A 2.0 Max 480Mbps bandwidth.
Supports BC 1.2 with max. 7.5 W (5V@1.5A) downstream charging
1x 3.5 mm audio jack* supports 48 K/44.1 KHz sampling rate audio output.
