Learn more about the GIGABYTE Z690I AORUS ULTRA PLUS DDR4
Model| Brand | GIGABYTE |
|---|
| Model | Z690I AORUS ULTRA PLUS DDR4 |
|---|
Supported CPU| CPU Socket Type | LGA 1700 |
|---|
| CPU Type | Celeron / Core i3 / Core i5 / Core i7 / Core i9 / Intel Core 12th Gen (LGA 1700) / Intel Core 13th Gen (LGA 1700) / Pentium Gold |
|---|
Chipsets| Chipset | Intel Z690 |
|---|
Onboard Video| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
Memory| Number of Memory Slots | 2x288pin (DDR4) |
|---|
| Memory Standard | DDR4 3200 |
|---|
| Maximum Memory Supported | 64GB |
|---|
| Channel Supported | Dual Channel |
|---|
Expansion Slots| PCI Express 5.0 x16 | 1 x PCI Express 5.0 x16 |
|---|
Storage Devices| Serial ATA (SATA) | 4 x SATA 6Gb/s |
|---|
| M.2 | 2 x M.2 |
|---|
Onboard LAN| Max LAN Speed | 2.5Gbps |
|---|
| Wireless LAN | Intel WiFi 6E |
|---|
Physical Spec| Form Factor | Mini ITX |
|---|
| LED Lighting | RGB |
|---|
Additional Information| First Listed on Newegg | February 22, 2026 |
|---|
