1 (The PCI Express x16 slot conforms to PCI Express 3.0 standard. To support PCI Express 3.0, you must install an Intel 22nm CPU.)
PCI Express x1
1 x PCI Express x1
PCI Slots
2 x PCI Slots
Onboard Audio
Audio Chipset
Realtek ALC887
Audio Channels
8 Channels
Onboard LAN
LAN Chipset
Atheros AR8151
Max LAN Speed
1Gbps
Rear Panel Ports
PS/2
2
LPT
1
Video Ports
D-Sub + DVI
USB 1.1/2.0
4 x USB 2.0
Audio Ports
3 Ports
Internal I/O Connectors
Onboard USB
4 x USB 2.0
Other Connectors
1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x serial port header 1 x Clear CMOS jumper
Physical Spec
Form Factor
Micro ATX
Dimensions (W x L)
9.6" x 7.87"
Power Pin
24 Pin
Features
Features
GIGABYTE Ultra Durable 4 Classic
Humidity Protection
Electrostatic Protection
Power Failure Protection
High Temperature Protection
PCI Express Gen.3 Support
Additional Information
First Listed on Newegg
July 18, 2012
