Main image of GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

100%

Alt view image 2 of 5 - GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

Alt view image 3 of 5 - GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

Alt view image 4 of 5 - GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

Alt view image 5 of 5 - GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

360^°

Shop All GIGABYTE Products

GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

Name: GIGABYTE GA-F2A68HM-H FM2+ Micro ATX Motherboards - AMD
Brand: GIGABYTE
SKU: N82E16813128950
Rating: 5 (1 reviews)

REFURBISHED

(1) Write a Review

AMD A68H
A- Series (FM2+) / Athlon Series
DDR3 2400(OC) /2133 /1866 /1600 /1333

Overview

Specs

Reviews (1)

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 90 days
Limited Warranty period (labor): 90 days
Read full details

Return Policies

Return for refund within: Non-refundable

Return for replacement within: 30 days

This item is covered by Newegg.ca's Replacement Only Return Policy.
Read full return policy for details.

Manufacturer Contact Info

Manufacturer Website
Support Phone: 1-626-854-9338
Support Website
View other products from GIGABYTE

Number of Memory Slots	2x240pin
Memory Standard	DDR3 2400(OC) /2133 /1866 /1600 /1333
Maximum Memory Supported	64GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 3.0 standard.) * To support PCI Express 3.0, you must install an FM2+ APU.
PCI Express x1	1 x PCI Express x1 slot (The PCI Express x1 slot conforms to PCI Express 2.0 standard.)
PCI Slots	1 x PCI Slot

Serial ATA (SATA)	4 x SATA 6Gb/s
SATA RAID	0/1/10/JBOD

Audio Chipset	Realtek ALC887
Audio Channels	2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

LAN Chipset	Realtek GbE LAN chip
Max LAN Speed	1Gbps

GIGABYTE GA-F2A68HM-H FM2+ AMD A68H USB 3.0 HDMI Micro ATX Motherboards - AMD

Refurbished

Learn more about the GIGABYTE GA-F2A68HM-H

Customer Reviews of the GIGABYTE GA-F2A68HM-H

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Back I/O Ports	1 x D-Sub / 1 x HDMI / 1 x LAN (RJ45) / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 3 x Audio Jacks / 4 x USB 2.0/1.1
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x D-Sub port
HDMI	1 x HDMI
RJ45	1 x RJ45
USB 3.0	2 x USB 3.0/2.0 ports
USB 1.1/2.0	4 x USB 2.0/1.1 ports
Audio Ports	3 x audio jacks (Line In, Line Out, Mic In)

Onboard USB	4 x USB 2.0
Other Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x APU fan header 2 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x speaker header 1 x Clear CMOS jumper 1 x chassis intrusion header

Form Factor	Micro ATX
Dimensions (W x L)	8.90" x 6.85"
Power Pin	24 Pin

Model
Brand	GIGABYTE
Model	GA-F2A68HM-H

Supported CPU
CPU Socket Type	FM2+
CPU Type	A- Series (FM2+) / Athlon Series
