eShinreal PCIe x8 to Dual M.2 NVMe SSD Adapter support 2260/2280/22110 SSD
- Supports 2 PCIe M.2 NVMe SSDs.
- Compatible with PCIe Gen5, Gen4, Gen3.
- Computer with PCI Express Slot (x8) support PCIe Bifurcation mode.
- A heatsink must be installed when installing a PCIe Gen5 SSD.
- Operating on PCIe Gen4 is the most stable.
+
+
Overview
Specs
Reviews
Product Model:XIC PE482
Product Name: PCIe x8 to 2 Port M.2 NVMe SSDs Adapter
Interface Type:2*M.2 M-key Connectors
Support Equipment:2*M.2 NVMe SSD
Host Bus Type:PCIe x8
Ps. Motherboards BIOS needs to have PCIe Bifurcation Mode Support
XIC PE482 2 Ports M.2 Card is a great storage solution for any workstation with PCIe x8 bandwidth. It has two M.2 M-key connectors to accept two M.2 NVMe SSD Drives, So each M.2 SSD Drives has dedicated PCIe 4.0 x4 bus bandwidth. It allows user to add dual M.2 NVMe into any PCIe x8 slot to achieve their full potential bandwidth.
Features:
Supports 2 PCIe M.2 NVMe SSDs.
Compatible with PCIe Gen5, Gen4, Gen3.
Comes with a full-profile bracket (preinstalled), and also includes a low-profile bracket for a small form-factor computer.
Computer with PCI Express Slot (x8) support PCIe Bifurcation mode.
A heatsink must be installed when installing a PCIe Gen5 SSD.
Operating on PCIe Gen4 is the most stable.
Please kindly verify with your mainboard manufacture to make sure the motherboard BIOS support Bifurcation for the PCI Express you are using.
