Ergotron 60-609-216 StyleView Vertical Lift Low-Profile Keyboard & Monitor Mount
- Side-to-side pan of keyboard and display promote patient caregiver interaction while access data
- Slide-out Keyboard Tray can extend out an extra 5" (125 mm) for comfortable data entry
- With the keyboard folded up, total system depth is as little as 4.5" (114 mm)
- Ergonomic back-tilt keyboard tray with left or right mouse tray ensures wrists remain in a neutral position during data entry
- Patented counterbalance system provides smooth adjustment while maintaining touch-screen stability
- 9" (229 mm) vertical adjustment enhances ergonomics for multiple users
- Steel construction for long-lasting durability
- Right- or left-side cable management system conceals and organizes cords and makes cleaning a snap!
+
+
Overview
Specs
Reviews
Perfect for space-constrained patient exam rooms, the low-profile vertical lift provides 9" (23 cm) of smooth vertical adjustment and folds into a slim, compact unit when not in use. The slide-out, back-tilt keyboard enhances user comfort, while the monitor and keyboard pan capability promote patient-caregiver interaction. A unique cable management system conceals and organizes cords and makes cleaning a snap.
MAIN OVERVIEW FEATURES: Device Supported: Flat Panel Display,KeyboardMaximum Screen Size Supported: 24"Color: WhiteMaterial: SteelVESA Mount Standard: 75 x 75,100 x 100Compatibility: LCD
Warranty & Returns
Warranty, Returns, And Additional Information
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.ca's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-800-888-8458
- Support Email: customerservice@ergotron.com
- Support Website
- View other products from Ergotron
LOADING...
The Ergotron StyleView 60-609-216 is a low-profile vertical-lift mount for a flat-panel monitor and keyboard, suited to healthcare staff who need to enter data while interacting with patients. It offers 9 inches of height adjustment, side-to-side positioning, and a fold-down keyboard tray.
Recommended For
- Clinicians charting at the point of care in space-constrained patient exam rooms, where a wall-mounted workstation can fold close to the wall between uses.
- Care teams who need to turn the monitor and keyboard toward a patient or colleague while discussing information at the bedside or in an exam room.
- Shared clinical work areas where different staff members need to adjust the workstation within a 9-inch vertical range and use a slide-out keyboard tray.
- Patient-room staff who use a keyboard, mouse, or scanner during documentation and want those tools organized on an integrated tray.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | A shared-use or patient-care workstation that combines a flat-panel display with a keyboard, mouse and scanner accessories |
| Display Compatibility And Mounting | Supports flat-panel displays up to 24 inches with 75 × 75 mm or 100 × 100 mm VESA patterns. Maximum monitor weight is 25 lb; the listed total load includes the monitor and keyboard-tray contents, and monitors thicker than 3 inches may reduce capacity |
| Keyboard Tray And Movement | Fold-down keyboard tray extends up to 5 inches and pans left or right up to 120°. Its back tilt adjusts from 0° to −10°; the display pans up to 50°, depending on monitor size |
| Integrated Accessories | Includes a mouse pad, wrist rest and mouse pouch, with a scanner and mouse holder integrated into the keyboard tray |
| Materials And Care | Steel construction with a white finish; the exterior is easy to clean, and cable management can be configured on either side |
| Model Identifiers | Ergotron StyleView, model 60-609-216 |
