HP 2930M 48G with Slot Switch 2930M 48G with Slot Switch

HP 2930M 48G with Slot SwitchBrand NewProduct # JL321A The HP Aruba OfficeConnect 2930M Switch Series is designed for digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch offices. Aruba OfficeConnect 2930M Switch
Series Features: Switch Number of
Ports: 48
Switching Capacity: 176 Gbps ARM Cortex-A9 / 1.016 GHz Processor 1 GB DDR3 SDRAM 4 GB Flash Memory 1U Rack Mountable MAC Address Table Size: 32768
Entries Routing Protocol: - OSPF, RIP, RIP-1, RIP-2, IGM
Pv2, IGMP, RIPng, MLD, MLDv2 - OSP
Fv2, static IP routing, IGM
Pv3, OSP
Fv3, CIDR - static IPv6 routing, ECMP, static IPv4 routing
Remote Management Protocol: - SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP - RMON 3, RMON 9, RMON, Telnet, SNMP 3 - SNMP 2c, HTTP, SSH, SSH-2, CLI, XRMON
Authentication Method: RADIUS, PAP, CHAP, TACACS, TACACS+ Flow Control Quality of Service (QoS) ARP support BOOTP support DHCP Protection DHCP Server DHCP Support DiffServ Support IPv6 Support Dynamic ARP Protection Dynamic VLAN Support (GVRP) Class of Service (CoS) Virtual Extensible
LAN (VXLAN) Interfaces: - 44 x 1000Base-T - RJ-45 - 4 x Gigabit LAN - 1 x serial (console) - RJ-45 - 1 x USB - Type B - 1 x management -
RJ-45 Compliant Standards: - 80 PLUS Silver - CISPR 22 Class A - CSA C 22.2 No. 60950-1-07 Second Edition - EN 55022:2010 - EN 55024:2010 - EN 60825- 1:2007 - EN 60950- 1:2006 +A 11:2009 +A 1:2010 +A 12:2011 +A 2:2013 - CISPR 24 - CNS 13438 - EN 61000-3-2 - EN 61000-3-3 - FCC CFR47 Part 15 A - ICES-003 Class A - IEC 60825- 1:2007 - IEC 61000-3-2 - IEC 61000-3-3 - IEC 61000-4-11 - IEC 61000-4-2 - IEC 61000-4-3 - IEC 61000-4-4 - IEC 61000-4-5 - IEC 61000-4-6 - IEC 61000-4-8 - IEC60950- 1:2005 +A 1:2009 +A 2:2013 - UL 60950-1 Second Edition - VCCI Class A
Standards and Protocols: - IEEE 802.1 ab (LLDP) - IEEE 802.1 ad - IEEE 802.1D - IEEE 802.1 p - IEEE 802.1Q - IEEE 802.1 s - IEEE 802.1 v - IEEE 802.1 w - IEEE 802.1AX - IEEE 802.1 x - IEEE 802.3 az - IEEE 802.3 x
