Camera: Number of cameras: 3
Number of preset positions: 9
Electronic gimbal
Lens FOV
Maximum pixels: 3x 50MP pixel
Depth of field: 0.7-8 meters
8 x digital zoom
Maximum resolution: 3840*2160
Video output resolution: 4k (2160p) 30fps, 1080p60fps
Effective focal length: 8.29 mm (Tele camera), 3.5mm (Wide camera)
Aperture: F/2.0-F/2.4
Supports wide dynamic range
Supports auto exposure
White balance: ATW/auto/manual
Shutter speed: 10ms-33ms
Minimum illumination: 0.5...
Additional Features: Camera
Smooth motorized pan, tilt and zoom
+/- 90 degree pan
+/- 35 degree / 45 degree tilt
10x HD zoom
Field of View:
Diagonal: 90 degree
Horizontal: 82.1 degree
Vertical: 52.2
Full HD 1080p 30 fps
H.264 UVC 1.5 with Scalable Video Coding (SVC)
Autofocus
3 camera presets plus home position button
Video mute / unmute LED indicator
Standard tripod thread
Remote Control
IR 28 ft. (8.5m) range
CR2032 battery (included)
Cables / Power
AC Power adapter with regional plugs
Power cable (9.8 ft. / 3m)
Mount
Dual-purpose bracket works for both wall mounting and tabletop elevation
Package Contents
PTZ Pro 2 Camera
Remote control
10-foot USB cable with power adapter connection
Power adapter with regional plugs
Mount
Documentation
Warranty card
System Requirements
Windows 7, Windows 8.1 or 10
macOS 10.10 or higher
Additional Features: Camera
Smooth motorized pan, tilt and zoom controlled from remote or console
Pan +/- 90 degree
Tilt +35 degree / -45
10x lossless HD zoom
Field of View:
Diagonal: 90 degree
Horizontal: 82.1 degree
Vertical: 52.2
Full HD 1080p 30fps
H.264 UVC 1.5 with Scalable Video Coding (SVC)
Autofocus
5 camera presets
Far-end control (PTZ) of ConferenceCam product (with supported services)
Kensington security slot
Video mute / unmute LED indicator
Standard tripod thread
Remote Control
Camera, speakerphone, and call control
5 camera presets
Docks on speakerphone
IR 8.5m / 28-foot range
CR2032 battery (included)
Speakerphone
Full-duplex performance
Acoustic echo cancellation
Noise reduction technology
Ultra-wideband audio
Pairs with mobile devices via Bluetooth and NFC
LCD for caller ID, call duration and other functional response
LEDs for speakerphone streaming, mu...
Specification: Tap IP
Touch Screen: 10.12 in (257 mm) diagonal screen with 14° display angle
Resolution: 1280 x 800
Cabling: Power over Ethernet (PoE) cable (not included), IEEE 802.3af Type 1, Class 3 device
Cable Management: Internal cable retention and strain relief system
Ethernet: 10/100 Mbps
WiFi: 802.11a/b/g/n/ac
Device Management: Logitech Sync
Color: Graphite
Mounting: 3.94 x 3.94in (100 x 100 mm) VESA FDMI
Rally Bar Huddle
Built-in Components: 6 DMIC microphone array, digital PTZ camera, 1 full range ported speaker, cable management & retention system, multi functional mount, integrated motorized privacy shutter, Logitech CollabOS platform
Enclosure: All-in-one enclosure with field replaceable front cover
Device Management: Logitech Sync
Displa...
Specification: Screen
Size: 10.1" (256.54 mm) diagonal
IPS (In-Plane Switching)
LCD Panel with LED Backlighting
Resolution: 1280 x 800 resolution
Touch: Capacitive, 10 points multi-touch
Brightness: 400 nits
Contrast: 1000:1
Anti Fingerprint: Oleophobic coating
Viewing angle: 85 degrees (U/D/L/R)
Position angle: 0 degrees (flat on mounting surface)
General
Integrated accelerometer
Integrated ambient light sensor
100 mm x 100 mm VESA FDMI
Cable exits: horizontal / vertical / center
Compatibility and Certifications
Logitech Tap Scheduler integrates with leading room scheduling solutions as a
Microsoft Teams Panel
Zoom Rooms Scheduling Display
Robin-Powered scheduling panel
Meetio scheduling panel
Package Contents
Logitech Tap Scheduler (White)
Multi-surface mount (glass/drywall)
Corner mount accessory
Mullion mount
Mounting hardware
Documentation
Camera: Ultra-HD imaging system supports:
4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
1080p, 720p at 30fps and 60 fps
Additional Features: Studio-Quality Video
With an Ultra-HD imaging system, Rally delivers brilliantly sharp video, outstanding color, and exceptional optical accuracy at resolutions up to 4K. Logitech RightLight technology optimizes light balance to emphasize faces and render natural-looking skin tones, even in dim or backlit conditions.
Advanced Modular Audio
Crystal-clear audio is essential for world-class video conferencing, and Rally excels in delivering sound that's natural, crisp, and highly intelligible. Logitech RightSound® enhances voice clarity by suppressing background noise, auto-leveling voices, and focusing on active speakers. Exquisitely sensitive mic pods ensure that everyone in the meeting can be clearly heard while stand-alon...
Camera: Digital Pan: ±48° at 4x zoom
Digital Tilt: ±32° at 4x zoom
Zoom: 4X HD digital zoom
Diagonal Field of View: 120°
Horizontal Field of View: 113°
Vertical Field of View: 80°
Resolution: 4k
Additional Features: Front of Room Audio
With Rally Speakers at the front of the room, voices and video always come from the same direction — and never from behind you, a problem with tabletop speakerphones. With Rally Mic Pods on the table and Rally Speakers at the display, conversations feel natural and lifelike.
Anti-Vibration Enclosure
An ingenious suspension system decouples the speaker module within the external enclosure, virtually eliminating the vibrations that can travel through walls, stands, and tables. This patent-pending design enables the superior echo cancelling performance of Rally Mic Pods, while ensuring that video images remain clear and steady, even at high volume levels and when zoomed in.
Comfortable Volume in Larger Rooms
Turn up the clarity while keeping volume at a comfortable level for everyone in the room. With sound coming from two speakers r...
Specification: Ports
2 USB Type-A 5Gbps signaling rate; 1 HDMI-in 2.0; 1 line in; 1 line out; 2 HDMI-out 2.0 (video); 1 PoE+ 802.3at-class 4 LAN RJ-45; 1 LLN RJ-45; 1 USB Type-C® 5Gbps signaling rate (with DisplayPort™ Alt Mode for video input)
Security management
802.1x support
Special features
Speaker framing; People framing; Group framing; Presenter tracking; DirectorAI perimeter supported
