Console Connectors: Keyboard: 1 x USB Type A Female (White)
Video: 2 x HDB-15 Female (Blue)
Mouse: 1 x USB Type A Female (White)
Speakers: 1 x Mini Stereo Jack Female (Green)
Mic.: 1 x Mini Stereo Jack Female (Pink)
Main: 1 x RJ-45 Female (Black)
Sub: 1 x RJ-45 Female (Black)
Specifications: Connector on First End:1 x HD-15 Male VGA
Connector on Second End:1 x HD-15 Male VGA
1 x Mini-DIN Male Keyboard/Mouse
1 x Type A Male USB
Specifications: TO PC/Source Interface:
USB: USB Type A Male
Mini Stereo Jack: 3.5mm Audio Jack (Speaker)
Video Output: DisplayPort Male
TO Switch Interface:
USB: USB Type B Male
Mini Stereo Jack: 3.5mm Audio Jack (Speaker)
Video Output: DisplayPort Male
Note: For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a
Features: The 2L-7D02UDPX5 Secure KVM Cable kit offers high- quality data connections between the Secure KVM Switch and your DisplayPort dual display servers and computers. The TAA-compliant cable kit enables the connection of Video, USB Keyboard/Mouse/CAC, and Audio (Speaker), delivering excellent performance with ATEN PSS PP v3.0 Secure KVM Switches.
Package Content: 1 x 2L-7D02UDPX5 1.8M USB DisplayPort Dual Display Secure KVM Cable Kit
PC Connectors: 4 x USB3.1 Gen1 Type B Female (Blue)
4 x DisplayPort Female (Black)
4 x Mini Stereo Jack Female (Green)
4 x Mini Stereo Jack Female (Pink)
Specifications: Connectors: 1 DB-25 Female, RS-485 / RS-422 Four Terminal Block, RJ11
Data Rate: Up to 100 Kbps under 4000ft.
Function Switches: SW1(DCE, DTE), SW2(TxON, RxON,TxRTS, RxON,TxDTR/RTS, RxDSR/ON)
Specifications: Connector on First End:1 x HDMI Male Digital Video
1 x Type A Male USB
2 x Mini-phone Male Stereo Audio
Connector on Second End:1 x HDMI Male Digital Video
1 x Type B Male USB
2 x Mini-phone Male Stereo Audio
Cable Type:USB/Mini-phone/HDMI
Device Supported:KVM Switch
