Wenglor Sensor Switch I18H008 PNP New

Wenglor Sensor Switch I18H008 PNP New

Switching Distance 12 mm
Correction Factors Stainless Steel V2A/CuZn/Al 0,94/0,43/0,41
Mounting semi-flush
Mounting A/B/C/D in mm 18/46/36/5
Mounting B1 in mm 0...26
Switching Hysteresis < 10 %
Housing Material CuZn, nickel-plated
Degree of Protection IP67
Connection M12 × 1; 4-pin
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 12 mA
Switching Frequency 380 Hz
Temperature Drift < 10 %
Temperature Range -40...80 °C
Switching Output Voltage Drop < 1 V
Switching Output/Switching Current 150 mA
Residual Current Switching Output < 100 µA
Short Circuit Protection yes
Reverse Polarity and Overload Protection yes
Protection Class III

MTTFd (EN ISO 13849-1)

3706,54 a

Error Indicator

yes

PNP NO

yes
