TURCK NI10-G18-AN6X 46423 Inductive sensor NPN
Order number: 46423
Threaded barrel, M18 x 1
Chrome-plated brass
DC 3-wire, 1030 VDC
NO contact, NPN output
Terminal chamber
EAN 4047101142952
eCl@ss-Code (V 5.1. 4): 27270101 -/- Inductive proximity switch
Customs tariff number 85365019
Country of origin CN
Weight 82 g
Technical Data
Design Threaded barrel
Construction size Threaded barrel, M18 × 1
Rated switching distance 10
Operating voltage DC
Switching element function NO contact
Output function NPN
Electrical connection Terminal chamber
Housing material Metal
Housing quality CuZn
Housing surface Chrome-plated
Mounting Non-flush
Order number: 46423
Threaded barrel, M18 x 1
Chrome-plated brass
DC 3-wire, 1030 VDC
NO contact, NPN output
Terminal chamber
EAN 4047101142952
eCl@ss-Code (V 5.1. 4): 27270101 -/- Inductive proximity switch
Customs tariff number 85365019
Country of origin CN
Weight 82 g
Technical Data
Design Threaded barrel
Construction size Threaded barrel, M18 × 1
Rated switching distance 10
Operating voltage DC
Switching element function NO contact
Output function NPN
Electrical connection Terminal chamber
Housing material Metal
Housing quality CuZn
Housing surface Chrome-plated
Mounting Non-flush
