Supermicro SY SYS-E50-9AP Atom E3940 FCBGA1296 8GB DDR3L 2.5 SATA SSD

Overview

Specs

Reviews

Model
Brand	SUPERMICRO
Model	SYS-E50-9AP

CPU Supported
CPU Type	Intel Atom processor E3940 Single socket FCBGA 1296 9.5W, 4C
CPU Socket	FCBGA 1296

Memory Supported
Max Memory Supported	Up to 8GB Unbuffered non-ECC SO-DIMM, DDR3L-1866 MHz, in 1 x DIMM socket
Memory Type Supported	DDR3L up to 1866 MHz

Expansion Slots
PCI Express	1 x Full size Mini-PCIe 1 x Half size Mini-PCIe

Communications
Number of LAN	Dual LAN with Intel Ethernet Controller I210-IT

Panel Ports
Rear USB	2 x USB 3.0 ports (rear)
RJ45	2 x RJ45 Gigabit Ethernet LAN ports

Power Supply
Max. Power	40W lockable 12V DC power adapter

Features
Features	Intel Atom processor E3940 (9.5W, 4C) Single socket FCBGA 1296 System on Chip 1 x SATA 3.0 for 7mm 2.5" SATA SSD, 1 x M.2 B-Key 2242/3042 for SATA SSD Up to 8GB 1866 MHz DDR3L Non-ECC SO-DIMM in 1 socket 1 x Full size Mini-PCIe, 1 x Half size Mini-PCIe, 1 x M.2 B-Key 2242/3042, 1 x M.2 E-Key 2230 Dual LAN with Intel I210-IT 2 x USB 3.0, 2 x USB 2.0, 2 x COM (RS-232/422/485), 1 x TPM 2.0 onboard Fanless design Lockable 12V DC 40W power adapter

Details
Form Factor	Proprietary

Dimensions & Weight
Dimensions	1.72" x 5.82" x 4.64"

Additional Information
First Listed on Newegg	March 05, 2019

Warranty & Returns

Return for refund within: Non-refundable

Return for replacement within: 30 days
