Supermicro 1U Gold Series WIO Server (SYS-511E-WR-G1)

This item is covered under the Manufacturer Only Return Policy.

Specs

Reviews

Learn more about the Supermicro SYS-511E-WR-G1

Details
Workload	General Purpose Server
Type	Rack
Rack Height	1U
LEDs	Fan Fail/System Over Heat LED HDD activity LED Network Activity LEDs Power status LED Unit Identification (UID) LED
Hot-swap Fans	5 middle cooling PWM 40x40x56mm Fan(s)

Memory
Installed Memory Size	64GB
Memory Type	DDR5 5600
Max Memory Capacity	4TB
Memory Features	Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM Max Memory (2DPC): Up to 4TB 4400MT/s ECC DDR5 RDIMM
Number of Memory Slots	16

Storage
SSD (Installed)	1 x 960GB M.2 NVMe SSD

Networking
Ethernet Controller	1 x 2 1GbE RJ45 LAN Ports

Expansion & Ports
Expansion Bays	4 front hot-swap 3.5" SAS*/SATA drive bays 1 M.2 PCIe 3.0 x2 NVMe slot (M-key 2280/22110)

Power
Power Characteristics	2x 860W Redundant (1 + 1) Titanium Level (96%) power supplies

Environmental
Temperature	Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -30°C to 60°C (-22°F to 140°F)
Humidity	Operating Relative Humidity: 8% to 80% (non-condensing) Non-operating Relative Humidity: 8% to 90% (non-condensing)

Dimensions & Weight
Dimensions	1.7" x 17.2" x 23.6"
Weight	21.5 lbs.

Additional Information
First Listed on Newegg	July 29, 2025
