Operating System: Embedded Linux Supported Clients - Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2 - Apple Mac OS X - Linux & UNIX
Processor
Quad Core Intel Xeon E3-1225 Processor 3.1 GHz
Installed Memory
4GB DDR3 ECC RAM Note: 1. The system memory can be increased to 16GB by installing Three additional 4GB Long-DIMM RAM modules. 2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide
Hard Drive Performance
Included HDD Capacity
Diskless System
Conveniences
Supported Protocols
Networking - TCP/IP (IPv4 & IPv6: Dual Stack) - Multiple Gigabit NICs with Jumbo Frame Failover Multi-IP Settings Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb) - Service Binding based on Network Interfaces - Virtual LAN (VLAN) - DHCP Client, DHCP Server - Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, - SNMP, SMTP, and SMSC - UPnP & Bonjour Discovery - USB Wi-Fi Adapter Support
Management
Disk Management - Single Disk, JBOD, RAID 0, 1, 5, 5 + Hot Spare, 6, 6 + Hot Spare, 10, 10 + Hot Spare - Online RAID Capacity Expansion & Online RAID Level Migration - Bad Block Scan & Hard Drive S.M.A.R.T. - Global Hot Spare Drive (4-bay NAS and above) - RAID Recovery - Bitmap Support
Power Management - Wake on LAN - Internal Hard Drive Standby Mode - Scheduled Power on/off (Max 15 Settings) - Automatic Power on after Power Recovery - USB and Network UPS Support with SNMP Management
Access Right Management - Max No. of Users: 4,096 - Max No. of User Groups: 512 - Max No. of Network Shares: 512 - Batch Users Creation - Import/Export Users - User Quota Management - Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File
Power
Power
Power Consumption (W) - Sleep mode: 89.1 W - In Operation: 229 W (with 16 x 1TB hard drive installed)
Features
Features
NAS, iSCSI, IP-SAN storage solution
VMware, Citrix and Hyper-V ready
High performance, secure, reliable, and simple
10 GbE ready reaching over 1,000 MB/s and 100,000 IOPS
Multi-core processor, DDR3, SATA 6Gb/s, and USB 3.0
