Specifications: Essential Tools for Cable Installers or Telecom/LAN Personnel
Tests Cat5, Cat6, Cat6a and telephone cable assemblies
Cable tester combines main tester unit and removable remote tester unit
Identifies connection, no connection, short circuit or open circuit
Tests multiple types: RJ11, RJ12, RJ45
Fast and slow LED flashing modes during automatic testing
Designed to Make Your Work Easier
Includes cable tester, crimping tool, LSA punchdown tool and stripper tool
Stores away in convenient carrying case
Side A - Connector 1: RJ45 (FEMALE)
Side B - Connector 1: RJ45 (FEMALE)
Specifications: Tripp Lite's professional grade, high-volume Punch Down Cable Installation Tool, with adjustable impact, is the perfect multi-purpose tool for punching down Cat5/Cat6 cable to 110 jacks and patch panels, or, telephone wire to 66M blocks. Each blade (110 or 66) contains a cutting and non-cutting side. The blade not being used is stored in the handle compartment. Adjustable High/Low actuation setting accommodates termination requirements or installer preference.
Specifications: Reversible Ratchet Handle
10Pcs Bit Group:
SL5-SL6 ; PH1-PH2 ; PZ1-PZ2
T10-T15-T20 ; Adapter
5Pcs Socket 3/16"-1/4"-5/16"-11/32"-3/8"
Anti-Static/ Anti Shock Wrist Band
6Pcs Precision Screwdriver
4 1/2" Side Cutter
5" Long Nose Pliers
Flashlight
RJ45 Modular Crimping Tool
8P8C Modular Plug
Protection Cap
Magic Cable Tie
Cable Tester
See through Blow Mold Case
Features: Cut and strip flat cable by one option Functions for 8P/RJ-45 and 6P/RJ-12, RJ-11 All steel construction for long term durability Crimps two sizes of plugs Built-in cutter and stripper Precision ground Compact size, easy to handle Ratchet mechanism to keep tool closed when not in use
Specifications: Pro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume dial
Replaceable tip
3.5 mm earphone jack
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Specifications: Application/Usage: Cable Termination
Additional Information:
Unique design easily accommodates close-to-wall installation.
Replaceable blade head for use with multiple jack types.
For Leviton 61110, 5G110, 6110G.
