Specifications: Safety
IEC 60950-1, EN 60950-1, CB Certificate/Report, UL/CSA 60950-1
EMC
CC / ICES-003 Emission (USA/Canada)
CRISP 22 Emission (International)
EN61000-4-2 Electrostatic Discharge
EN61000-4-3 Radiated RFI Immunity
EN61000-4-4 Electrical Fast Transients level 4
EN61000-4-5 Electrical Surge Level
EN61000-4-6 RF Conducted
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
EN61000-4-8 Power Frequency Magnetic Fields
EN61000-4-11 Voltage Dips and Interruptions
Specifications: Interface:
Wi-Fi
Micro USB (Support USB 2.0)
Color: White
Capacities: 32GB
Network Standard: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Operating Frequency: 2.4 GHz / 5 GHz
Ports:
1 x SD Card Reader
1 x Micro USB
Button: Reset Button, Power Button, Channel Switch
LED Indicator:
1 x Power
1 x Wi-Fi
System Requirements:
Windows 10 86x64
Windows 8 86x64
Windows 7 86x64
Mac OS X 10.6 or higher
iOS7 or higher
AndroidTM 4.0 or higher
Kindle Fire HD and HDX
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
Device Interface:
1 x Gigabit data/power in port
1 x Gigabit data out port
1 x Power out port
LED indicators
Adjustable output power DIP switch (5 V, 7.5 V, 9 V, 12 V)
Data Transfer Rate:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Jumper Cable:
2.0 to 2.0 mm
2.0 to 2.5 mm
Power:
PoE network cable input: 48 V DC, 0.38 A
Output: 5 V (2 A), 7.5 V (2 A), 9 V (1.7 A), 12 V (1.2 A)
Consumption: 0.3 Watts (max.)
Specifications: Industry Standards:
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Ports: 4
Maximum Cable Length: 328 ft [100 m]
Maximum Data Transfer Rate: 2 Gbps (Full-Duplex)
MTBF: 50,000 Hours
Power Output: 52V DC at 30.8W (PoE+)
Connector Type(s): 8 - RJ-45 Female
Enclosure Type: Steel
LED Indicators: 1-Power, 4-PoE In-Use
Center Tip Polarity: Positive
Input Current: 2-1 A
Input Voltage: 100 ~ 240 AC
Output Current: 2.31 A
Output Voltage: 52 DC
Plug Type: M
Power Consumption: 120 W Max
Power Source: AC Adapter Included
Included in Package:
1 - 4 Port Gigabit PoE+ Injector
1 - Universal Power Adapter
3 - Power Cords (NA/UK/EU)
1 - Instruction Manual
Features: • Converts a non-PoE 2.5G port to a PoE++ 2.5G port
• Supplies PoE (15.4W), PoE+ (30W), or PoE++ (90W)
• Network a PoE device up to 100m (328 ft.)
• Integrated power supply
• 2.5GBASE-T compliant
• IEEE 802.3af, 802.3at, and 802.3bt compliant
Specifications: Standards
IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High-Power PoE+ Power over Ethernet)
IEEE 802.3 (10Base-T Ethernet)
IEEE 802.3u (100Base-TX Fast Ethernet)
Media support:
10Base-T Cat3, 4, 5 UTP/STP RJ45
100Base-TX Cat5 UTP/STP RJ45
Ports:
1 RJ45 10/100 Mbps input port for 48 V IEEE 802.3af-compliant signal
1 RJ45 10/100 Mbps output port
1 power output port
Certifications: FCC Class A, CE
LEDs: LINK
Power
Output power:
5, 7.5, 9 or 12 V DC, selectable via switch
Maximum output: 5 V - 4 A, 7.5 V - 2.7 A, 9 V - 2.3 A, 12 V - 1.7 A
Polarity, outer: negative ( - ); inner: positive ( + )
Power consumption: 25.4 Watts (maximum)
Environmental
Metal housing
Dimensions: 4.00" x 2.90" x 0.90"
Weight: 0.24 kg (0.5 lb.)
Operating temperature: 0 - 60°C (32 - 140°F)
Operating humidity: 10 - 90% RH, non-condensing
Storage tem...
Specifications: Technical Information
Protection Type:
ESD Protection
Power Description
Input Voltage:
120 V AC
230 V AC
Maximum Output Voltage:
54 V DC
Maximum Input Current:
2.50 A
Maximum Output Current:
3.30 A
Maximum Output Power:
160 W
Interfaces/Ports
Output Ports:
4 x Multi-Gigabit PoE++
Physical Characteristics
Product Color:
Black
Form Factor:
DIN Rail/Wall Mountable
Height:
1.5"
Width:
2.8"
Length:
3.7"
Weight (Approximate):
9.80 oz
Miscellaneous
Package Contents:
PoE++ Injector
1 x Universal Power Adapter
1 x DIN Rail Mounting Kit
1 x Quick-Start Guide
Compatibility:
IP cameras
access control devices
remote kiosks (POSs)
wireless access points
PoE lighting
digital signage.
Certifications & Standards:
IEEE 802.3af
IEEE...
