Mobile Rack Drives Support: 1 x 3.5" Drives to 5.25" Bay
Mobile Rack Interface: SATA I/II
Specifications: Hard Drive Compatibility: 3.5-Inch SATA/300(SATA II) or SATA/150 (SATA I) Hard Drives
System Requirements: PC or Mac with a 5.25 Inch Drive Bay
Drive Drawer Dimensions: 7.5" x 5.8" x 1.6"
Cooling Fan: Ball-Bearing Fan
Fan Dimensions: 40 x 40 x 10mm
Fan Enclosure: Plastic
Drive Drawer Enclosure: Aluminum
Drive Size: Supports up to 750Gb hard drive
Note: Unit is model specific and is not meant for use with different models of drive drawer unless otherwise stated
Specifications: Bus Type USB: 3.1 Gen 2
Chipset ID: ASMedia - ASM1352R
Compatible Drive Types: M.2 (NGFF, B-Key)
Drive Installation: Fixed
Interface: USB 3.1 Gen 2
Number of Drives: 2
Supported Drive Height(s): 2230, 2242, 2260, 2280
General Specifications Not compatible with PCI-Express M.2 SSDs
Maximum Data Transfer Rate: 10 Gbps
MTBF: 35,000
Port Multiplier: Yes
Trim Supported: Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 2 - Read / Write (green), 2 - Error / Rebuilt (red)
