TRENDnet TC-P24C6AS 24-port Cat6A Shielded 1U Patch Panel, 1000BASE-T / 10GBASE-T Support, compatible with cat5e, cat6, cat6a, 110 or Krone type- Type: Others
- Color: Black
- Specifications: Standards:
ANSI/ TIA/ EIA-568-B.2-1
ANSI/ TIA/ EIA-310-D
EN50173-1: 2002
ISO/ IEC 11801 2nd edition: 2002
Interface :
24 x Gigabit T568A/T568B wiring cards for Krone 110 termination
90° angle type
Compatible with 22 to 26 AWG solid wires
50 micron shielded gold plated jack connectors
Electrical Specification:
Dielectric Withstand Voltage: 1000V DC
Current rating: 1.5A at 68° F
Mechanical Specification:
Contact force 99.2g (3.5 oz.)
Plug retention force: 13.3kg (30 lb.)
110/ Krone IDC insertion force: min. 4.5kg (9.9 lb.)
110/ Krone IDC retention force: min. 0.5kg (1.1 lb.)
Operating Temperature: -25° – 50° C (-13° – 122° F)
Operating Humidity: Max. 90% non-condensing
Dimensions:
1U design
440 x 105 x 40mm (17.3 x 4.1 x 1.6 in.)
Weight: 1.6kg (3.5 lb.)
- Model #: TC-P24C6AS

Quick View
Cisco 110 CBS110-24PP Ethernet Switch, 24 Ports - 2 Layer Supported- Part Number: CBS110-24PP
- Format: Desktop
Wall Mountable
Rack-mountable
- Network Media: Media Type Supported:
Twisted Pair
Optical Fiber
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/ 1000Base-T
1000Base-X
- Uplink Interface: Total Number of Expansion Slots:
2.0
Expansion Slot Type:
SFP (mini-GBIC)
Shared SFP Slot:
Yes
Number of SFP Slots:
2
- Model #: CBS11024PPNA

Quick View
Cisco Business CBS110-24T Unmanaged Switch, 24 Port GE, 2 x 1G SFP Shared, Limited Lifetime Protection (CBS110-24T-NA)- Format: Desktop
- Standards: IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet
- Primary Ports: 24 x RJ45 + 2 x SFP
- Primary Port Speed: 10/100/1000Mbps
- Model #: CBS110-24T-NA
