Digital Temperature Controller Thermostat, AC/DC 24V-240V DIN Rail Mount with Probe, Heating and Cooling Mode for HVAC Industrial Equipment and Home Automation
- 1. Wide AC/DC 24V-240V power supply compatible with various industrial equipment and home automation systems.; 2. DIN rail mount design for easy installation in control panels and electrical cabinets.; 3. Built-in temperature probe with adjustable range -15 to +45 and hysteresis 0.5 to 5 for precise control.; 4. Switchable heating or cooling mode with SPST 16A relay output, green and red LED indicators for power and output status.; 5. Durable mechanical life of 10 million cycles and electrical life of 100,000 cycles, suitable for long-term use.
+
+
Overview
Specs
Reviews
Product description
Specification: Item
Type: Temperature Control
Relay Function: Monitor temperature range
Power Terminal: L-N
Rated Power Supply Voltage: AC/DC 24V-240V
Rated Power Frequency: 50/60Hz
Rated Impulse Withstand Voltage: 2.5 kV
Rated Insulation Voltage: 250V
Power Consumption: Maximum 2VA
Power Supply Allowable Fluctuation Range:
-15%: +10%
Temperature Adjustment Range: -15 to +45
Temperature Adjustment Hysteresis Value: 0.5 to 5°
Working Mode: Heating-cooling-on and off can be set
Power Indicator: Green LED
Output Contact Parameters: 1xSPST 16A/AC1 250VAC/24VDC
Minimum Switching Power: 500mW Output
Relay Indication: Red LED
Mechanical Life: 1x10000000 Electrical Life (resistive
Load): 1x100000 Working
Environment Temperature: -20 ~+55 Storage and Transportation
Environment Temperature: -35~+75
Installation Method: Approx. 35mm / 1.4 in rail
installation Protection Level: IP20
Installation Location: Any
Installation Altitude: Pollution
Degree: 2
Wiring Capacity: 1x 2.5 mm² or 2x 1.5 mm² 0.8N m
Package List: 1 x Temperature Control Relay 1 x Probe 1 x User Manual See More
Specification: Item
Type: Temperature Control
Relay Function: Monitor temperature range
Power Terminal: L-N
Rated Power Supply Voltage: AC/DC 24V-240V
Rated Power Frequency: 50/60Hz
Rated Impulse Withstand Voltage: 2.5 kV
Rated Insulation Voltage: 250V
Power Consumption: Maximum 2VA
Power Supply Allowable Fluctuation Range:
-15%: +10%
Temperature Adjustment Range: -15 to +45
Temperature Adjustment Hysteresis Value: 0.5 to 5°
Working Mode: Heating-cooling-on and off can be set
Power Indicator: Green LED
Output Contact Parameters: 1xSPST 16A/AC1 250VAC/24VDC
Minimum Switching Power: 500mW Output
Relay Indication: Red LED
Mechanical Life: 1x10000000 Electrical Life (resistive
Load): 1x100000 Working
Environment Temperature: -20 ~+55 Storage and Transportation
Environment Temperature: -35~+75
Installation Method: Approx. 35mm / 1.4 in rail
installation Protection Level: IP20
Installation Location: Any
Installation Altitude: Pollution
Degree: 2
Wiring Capacity: 1x 2.5 mm² or 2x 1.5 mm² 0.8N m
Package List: 1 x Temperature Control Relay 1 x Probe 1 x User Manual See More
