B1012 Needle Roller Bearings 5/8" x 13/16" x 3/4" Full Complement Drawn Cup 2pcs
- Model: B1012 (I.D. (Fw)=5/8", O.D. (D)=13/16", Width (C)=3/4");ST14 steel drawn cup, GCr15 needle rollers full complement bearing;Good heat tolerance, high load carrying capacity and stiffness
+
+
Overview
Specs
Reviews
Specification:
Model: B1012
Drawn Cup Material: ST14 Steel
Needle Roller Material: Chromium Steel (GCr15)
Accuracy: P0
Bore Diameter (Fw): 5/8" / 15.88mm
Outside Diameter (D): 13/16" / 20.67mm
Width: 3/4" / 19.05mm
Dynamic Load Rating: 4390N
Static Load Rating: 7130N
Limiting Speed: 6200Rpm
Number of Pack: 2 Pcs
Description:
-Drawn Cup Needle Roller Bearing features a deep drawn, thin-walled outer ring. They are compact bearings with high load carrying capacity and stiffness.
-These bearings are especially suitable for high dynamic loads or radial-limited installation. They are mounted with a tight interference fit in the housing.
-Shoulders or snap rings are not required to locate the bearing axially, thus enables a simple and economic design of the housing bore.
-For various applications such as automotive and truck transmissions, agricultural and construction equipment, pumps and compressors, and two-cycle engines, among others.
-NOTE: Install with press machine or special tools instead of hammers because beating may lead to local deformation or brittle fracture.
