HF081412 Needle Roller Bearings, One Way Bearing, 8mm Bore 14mm OD 12mm Width 3pcs

Model: HF081412 (I.D. (Fw)= 8mm, O.D. (D)= 14mm, Width (C)= 12mm).ST14 steel drawn cup, GCr15 needle rollers one way clutch.Good heat tolerance, high load carrying capacity and stiffness.

Overview

Specs

Reviews

Description:

KEY_TAB

Drawn Cup Needle Roller Bearing features a deep drawn, thin-walled outer ring. They are compact bearings with high load carrying capacity and stiffness.
These bearings are especially suitable for high dynamic loads or radial-limited installation. They are mounted with a tight interference fit in the housing.
Shoulders or snap rings are not required to locate the bearing axially, thus enables a simple and economic design of the housing bore.
For various applications such as automotive and truck transmissions, agricultural and construction equipment, pumps and compressors, and two-cycle engines, among others.
NOTE: Install with press machine or special tools instead of hammers because beating may lead to local deformation or brittle fracture.

KEY_TAB

Specification:

Model: HF081412

Drawn Cup Material: ST14 Steel

Needle Roller Material: Chromium Steel (GCr15)

Bore Diameter (Fw): 8mm

Outside Diameter (D): 14mm

Width: 12mm

Torque: 5N*m

Rotating Shaft Limiting Speed: 16000rpm

Rotating Outer Ring Limiting Speed: 12000rpm

Number of Pack: 3 Pcs
