Blue Sea Systems 2356100 100A Water-Resistant Busbar, Manual Cover
- Maximum Voltage: 300V AC/ 48V DC, Terminal Stud: 1 x #10-32, Continuous Rating: 100A AC/ 100A DC, Bus Material: Tin-Plated Copper C11000, Mounting Holes: Accepts 1/4" (6mm) Screws, Terminal Screws: 4 x #8-32, Wire Size: (1) 8 AWG to 4 AWG - Input/ (4) 16 AWG to 10 AWG - Load
- Water-resistant design with standard ring or spade type terminals allows for simple wiring with standard tools
- Accepts a wide range of wire sizes
- Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used, and 4 write-on circuit labels
- Wing-screws designed for tool-free installation of cover to meet ABYC compliance
- Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
- Ideal for positive distribution and for the collection of negative or AC ground circuits
+
+
Overview
Specs
Reviews
Maximum Voltage: 300V AC/ 48V DC, Terminal Stud: 1 x #10-32, Continuous Rating: 100A AC/ 100A DC, Bus Material: Tin-Plated Copper C11000, Mounting Holes: Accepts 1/4" (6mm) Screws, Terminal Screws: 4 x #8-32, Wire Size: (1) 8 AWG to 4 AWG - Input/ (4) 16 AWG to 10 AWG - Load
Water-resistant design with standard ring or spade type terminals allows for simple wiring with standard tools
Accepts a wide range of wire sizes
Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used, and 4 write-on circuit labels
Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
Ideal for positive distribution and for the collection of negative or AC ground circuits
Water-resistant design with standard ring or spade type terminals allows for simple wiring with standard tools
Accepts a wide range of wire sizes
Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used, and 4 write-on circuit labels
Wing-screws designed for tool-free installation of cover to meet ABYC compliance
Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
Ideal for positive distribution and for the collection of negative or AC ground circuits
