1.10C Version 50Khz-2GHz Malachite SDR Radio Software Malahit DSP SDR Receiver + LCD Touching Screen +

All types of analog modulation:AM,SSB,NFM,WFM, also with the CW decode function.
Multifunction:variable filter width, adaptive noise suppressor, threshold noise supp
Material:metal
Frequency:50kHz2GHz
Chip:msi001
Display:3.5inch
1:Improved the graphic display of the spectrum
2:Improved algorithm optimization and improved display speed
3:Added the function of determining the activation typeonly one or three
4:Improved the HARD menu
Certification:NONE
Origin:CN(Origin)

1.10C Version 50Khz-2GHz Malachite SDR Radio Software Malahit DSP SDR Receiver + LCD Touching Screen +
10c:- A button for switching audio output has been added to the HARD menu. It replicates the switching of audio output. Produced at the request of users.
Advantage: 1. 3.5 inch capacitive screen; 2. Adopting sound unit, 2 vibration chambers, the speaker has its own sound chamber, and the bass sound quality is very full
Malahit's DSP SDR receiver. Capacitive Touchscreen. Flash memory via USB cable. Default frequency range: 50KHz-200MHz
The radio is built on the principle of SDR-the function is determined by the loaded software
All types of analog modulation: AM, SSB, NFM, WFM
Powerful functions: variable filter width, adaptive noise suppressor, threshold noise suppressor, used for noise blanker, AGC, equalizer
Use the cheap but fully functional chip msi001
Use powerful stm32h743 with a clock frequency of 480MHz
3.5-inch IPS display Touchscreen
Built-in UHF
Controls: 2; encoder with buttons and Touchscreen
External TYPE-C (Huawei mobile phone) interface or power supply, can be charged through TYPE-C.
Consumption: 300mA when listening to headphones
The reception of built-in telescope or external antenna is to improve the HF reception of the telescope antenna, and an additional board with a source follower has been developed. The board will be built into the standard receiver design.
Connect to a computer via USB, which can transmit CAT, IQ and audio.
160 kHz span, with scalability
Due to the characteristics of the msi001 chip used, the dynamic blocking range is around 85dB.
With backlight control
SMA female antenna socket
Motherboard size: 100 x 70mm (without connector size).
Colour: black
Material: metal
Size: 21cm x 11.5 x 5cm
Package Contents:
1 x Malachite SDR Shortwave Radio
1 x USB C Cable
1 x Antenna adapter
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
