ASUS TUF B360M-PLUS GAMING S LGA 1151 Intel B360 Desktop Motherboard DDR4 64G Core i7-8700K i5-9600K Cpus 2×M.2 PCI-E 3.0 USB3.1

Quality Certification:ce
Chipset:Intel B360
Socket Type:LGA 1151
Storage Interface Type:SATA 3
Onboard LAN:1x RJ45
Package:No
Model Number:TUF B360M-PLUS GAMING S
Application:Desktop
With CPU:No
Special Function:None
Maximum Ram Capacity:64 GB
Chipset Manufacturer:Intel
Back I/O Ports:6 x USB 2.0
Support Memory Type:DDR4
Usage Scenario:Gaming
Number of PCI:0
PCI - E standards:PCI - E 3.0
Origin:CN(Origin)
Number of PCIe x 16:1
Memory channel:Double
Form Factor:CeB
Number of PCIe x 1:2
Certification:CE
Number of M.2:2

TUF B360M-PLUS GAMING S Parameters
Motherboard chip
Integrated chip sound card/network card
Main chipset Intel B360
Chipset description Using Intel B360 chipset
Display chip CPU built-in display chip (requires CPU support)
Audio chip integrated Realtek ALC887 8-channel audio chip
Network card chip onboard Intel I219V Gigabit network card
Processor specifications
CPU type 9th/eighth generation Core i7/i5/i3/Pentium/Celeron
CPU socket LGA 1151
CPU description Support Intel 14nm processor
Support Intel Turbo Boost 2.0 technology
Memory specifications
Memory type 4×DDR4 DIMM
Maximum memory capacity 64GB
Memory description Support dual-channel DDR4 2666/2400/2133MHz memory
Storage expansion
PCI-E standard PCI-E 3.0
PCI-E slot 1×PCI-E X16 graphics card slot, 2×PCI-E X1 slot
Storage interface 2×M.2 interface, 6×SATA III interface
I/O interface
USB interface 2×USB3.1 Gen2 interface (2 backplane), 3×USB3.1 Gen1 interface (2 built-in +1 backplane), 6×USB2.0 interface
Video interface 1×DVI interface, 1×HDMI interface
Power connector One 8-pin, one 24-pin power connector
Other interfaces
1×RJ45 network interface, 3×audio interface, 1×PS/2 keyboard and mouse universal interface, 1×8 channel audio interface, 2×chassis fan interface, 1×front panel audio interface (AAFP), 1×system panel interface
Board type
Motherboard board type Micro ATX board type
Dimensions 24.4×24.4cm
