8 Way Steering Gear Controller Debugging Board Futaba MG995 SG90 Steering Gear Debugging Board Return Instrument

Origin:CN(Origin)
Model Number:Eight-way steering gear controller debugging board

Product selling point:
1: Wide range of applications
2: Small size, easy to carry
3: stable performance
4: Simple to use
5: 4 Number of control channels: 8 channels;
Features:
1. The onboard STM32 is used to generate high-resolution PWM signals with precise control;
2 Support manual mode and return mode, switch by button, with mode indicator;
3. Support knob adjustment control in manual mode;
4. Number of control channels: 8 channels;
5. Steering gear control accuracy: 0.09 degrees (that is, the minimum change value of PWM is 1us);
6. Supports servos with a control period of 20ms and a pulse width of 0.5-2.5ms
7. You can directly use the 2S lithium charging head to debug and return the steering gear;
8. Power supply voltage range: 5-9V (depending on the actual power supply voltage of the servo used);
9. Each steering gear interface has a self-recovery fuse to prevent excessive current from burning out the steering gear;
Instructions for use:
The steering gear is a power-consuming device and consumes a lot of power, so the current of the power supply needs to be sufficient.
If the power indicator light flashes, the servo rotation is out of control or the error is obvious, it means that the power supply is insufficient and the power supply needs to be replaced.
Wiring:
Vcc and GND are connected to the power supply, and the servo is inserted into the 2X3P pin header, where VCC is the positive pole, GND is the negative pole, and S is the signal terminal.
The package includes:
1*8-channel steering gear controller debugging board
