Individually LED Full Color Icicles String DC12V WS2811 All White Wire IP68 60nodes/Set;with 2m 13.5mm/xConnect Pigtail(XConnect Pigtails)
- Input voltage: DC12V input
- IC type: WS2811256 grayscale; 24 bit RGB color
- LED type: 8mm round cap light, each LED is 0.24W
- Wire: all white wire; 20AWG
- Maximum power: 30W/set
+
+
Overview
Specs
Reviews
Protection level: IP68; Epoxy resin filling
Standard connection: 3-4-5-3-4-5-3-4-5-3-4-5-3-4-5 (they are the number of pixels per drop)
Strand spacing: 4 inches (10 centimeters) per drop of node spacing; The spacing between each droplet is 8 inches (20 centimeters), so the total length of each group is approximately 3 meters.
Control method: SPI signal input; Each LED operates as a pixel, so each group has a total of 60 pixels, with a tower of 180 DMXchannels. All pixels are connected in series, with a signal returning from the end of each droplet to the starting point of the next droplet.
Input end: 2 meters long, 3-pin white wire 13.5mm/x connected male
Output end: 0.2 meter long, 3-pin white wire 13.5mm/x connected to the female head
For tail fibers:
Brown: -5/12v+
Yellow: Data
Blue: grounded
Standard connection: 3-4-5-3-4-5-3-4-5-3-4-5-3-4-5 (they are the number of pixels per drop)
Strand spacing: 4 inches (10 centimeters) per drop of node spacing; The spacing between each droplet is 8 inches (20 centimeters), so the total length of each group is approximately 3 meters.
Control method: SPI signal input; Each LED operates as a pixel, so each group has a total of 60 pixels, with a tower of 180 DMXchannels. All pixels are connected in series, with a signal returning from the end of each droplet to the starting point of the next droplet.
Input end: 2 meters long, 3-pin white wire 13.5mm/x connected male
Output end: 0.2 meter long, 3-pin white wire 13.5mm/x connected to the female head
For tail fibers:
Brown: -5/12v+
Yellow: Data
Blue: grounded
