| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
|---|---|
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 0 to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 50 2 m (6.5 ft) drops to concrete at -30°C |
| Tumble | 5,000 1 m (40 in) tumbles |
| ESD | ±20Kv air discharge, ±8kV contact discharge |
| Environmental Sealing | IP65 |
| Light Levels | 0 to 100,000 lux (9,290 foot-candles) |
| Input Voltage | 4.0 to 5.5 VDC |
| Operating Power | 2.35W (470mA @ 5.0V) |
| Standby Power | 0.5W (100mA @ 5.0V) |
| Host System Interfaces | USB and True RS232 |
| Scan Pattern | Area Imager |
| Scan Angle | Horizontal: 12.9° Vertical: 8° |
| Symbol Contrast | 1D Codes: 30% minimum reflectance difference |
| 2D Codes | 40% minimum reflectance difference |
| Min. Resolution | 1D & 2D Codes: 2 mil |
| Pitch, Skew | 70°, 80° |
| Dimensions | 133 mm x 75 mm x 195 mm (5.2 in x 2.9 in x 7.6 in) |
| Weight | 14.82 oz |
| Connectivity Technology | Wireless |
| Scanning Distance | 49.21 ft |
| Maximum Ambient Light | 100000 lux |
