4K HDMI Matrix Switch 6x2, 6 in 2 Out Video Multi-viewer Switcher Splitter Audio Extractor Multiviewer with IR Remote- Support Ultra HD 4K x 2K, 3D 1080P @60hz,ARC,PIP, EDID

The 6x2 HDMI Matrix supports the feature of PIP, ARC, 4K and 3D, which can switch or splitter the six HD input sources to the two HD Displays. It also can do the audio extract by the Optical port or HP port. ARC feature can let you return your TV audio to the av receiver; the PIP feature can let you choose the input sources channel by watch the small picture window at the Display.



HDMI resolution: 4KX2K/3D/1080p/1080i/720p/576p/576i/480p/480i
Support HDMI audio format:. DTS-HD/Dolby-trueHD/LPCM/DTS/Dolby-AC3/DSD
Digital Audio Output Supported Audio Format: LPCM 2.0 /Dolby AC3/ DTS
Digital Audio Output Sampling Rate: 32KHz, 44.1KH z, 48KHz, 88.2KH z, 96KHz, 176.4KH z, 192KHz
Max transmission bandwidth: 300MHz
Max baud rate: 9.0G bps
Input/Output TMDS signal: 0.5 ~ 1.5V olts p-p
Input/Output DDC signal: 5Volts p-p (TTL)
Max working current: 700mA
