$7,217.55
Ships from United States.
Meet Your Seller
Cisco Nexus 92348GC-X 54 Ports Manageable Ethernet Switch, 3 Layer Supported, Modular, Twisted Pair, Optical Fiber, 1U, Rack-mountable
- The Cisco Nexus 92348GC-X Switch is a 1RU switch based on Cisco Cloud Scale technology and supports 0.696Tbps of bandwidth and over 250mpps. Ideal for big data customers that require a Gigabit Ethernet ToR switch with local switching and for management switch use cases.
- Can work as layer 3 routing for scalable network design
- Rack mounting enables you to organize wires & secure cables for professional installation
- Management capability provides control over setup and configuration of your network
- Lets you conveniently connect to the gigabit ethernet Ethernet technology to offer maximum productivity
- Twisted Pair media support ensures maximum convenience and great usability
- Quickly and easily set up a wired network with 54 networking ports
- Effectively reduces downtime with improved network performance
+
+
Overview
Specs
Reviews
- Brand Cisco,
- Model N9K-C92348GC-X
- Product Description: Cisco Nexus 92348GC-X - switch - 48 ports - managed - rack-mountable,
- Device Type: Switch - 48 ports - L3 - managed,
- Enclosure Type: Rack-mountable 1U,
- Subtype: Gigabit Ethernet,
- Ports: 48 x 10/100/1000 + 4 x 1/10/25 Gigabit SFP28 + 2 x 40/100 Gigabit QSFP28,
- Performance: Bandwidth: 3.2 Tbps,
- Capacity: Longest prefix match (LPM) entries (IPv4): 16000 ¦ Longest prefix match (LPM) entries (IPv6): 20000 ¦ IPv4 routes (Multicast): 32000 ¦ Virtual interfaces (VLANs): 4096 ¦ Equal-Cost Multipathing (ECMP) ways: 64 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ Rapid Per-VLAN Spanning Tree Plus instances: 507 ¦ Virtual Routing and Forwarding (VRF) entries: 16000 ¦ IGMP snooping entries: 32000 ¦ ACL entries (ingress): 4000 ¦ ACL entries (egress): 2000,
- MAC Address Table Size: 96K entries,
- Routing Protocol: RIP-2, BGP, IGMP, MSDP, ECMP,
- Power: AC 120/230 V (50/60 Hz) - power supply not installed,
- Power Redundancy: Yes,
- Dimensions (WxDxH): 17.3 in x 22.5 in x 1.7 in,
- Weight: 14.11 lbs,
- Manufacturer Warranty: 1-year warranty,
- Device Type: Switch - 48 ports - L3 - managed,
- Enclosure Type: Rack-mountable 1U,
- Subtype: Gigabit Ethernet,
- Ports: 48 x 10/100/1000 + 4 x 1/10/25 Gigabit SFP28 + 2 x 40/100 Gigabit QSFP28,
- Performance:Bandwidth: 3.2 Tbps,
- Capacity:Longest prefix match (LPM) entries (IPv4): 16000 ¦ Longest prefix match (LPM) entries (IPv6): 20000 ¦ IPv4 routes (Multicast): 32000 ¦ Virtual interfaces (VLANs): 4096 ¦ Equal-Cost Multipathing (ECMP) ways: 64 ¦ Multiple Spanning Tree Protocol instances: 64 ¦ Rapid Per-VLAN Spanning Tree Plus instances: 507 ¦ Virtual Routing and Forwarding (VRF) entries: 16000 ¦ IGMP snooping entries: 32000 ¦ ACL entries (ingress): 4000 ¦ ACL entries (egress): 2000,
- MAC Address Table Size: 96K entries,
- Routing Protocol: RIP-2, BGP, IGMP, MSDP, ECMP,
- RAM: 8 GB,
- Flash Memory: 16 GB,
- Status Indicators: Status,
- Expansion / Connectivity
- Interfaces: 48 x 10/100/1000 Base-T RJ-45 ¦ 4 x 1/10/25Gbit LAN SFP28 ¦ 2 x 100Gbit/40Gbit LAN QSFP28 ¦ 1 x USB ¦ 1 x management RJ-45 ¦ 1 x management SFP+ ¦ 1 x serial (RS-232),
- Power Device: Internal power supply (not installed) - hot-plug,
- Max Supported Qty: 2,
- Power Redundancy: Yes,
- Power Redundancy Scheme: 1+1,
- Voltage Required: AC 120/230 V (50/60 Hz),
- MTBF: 379,400 hours,
- Compliant Standards: CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, GB 4943, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1 Second Edition, EN 300 386, KN 61000-4, AS/NZS CISPR22 Class A,
- Dimensions & Weight
- Width: 17.3 in,
- Depth: 22.5 in,
- Height: 1.7 in,
- Weight: 14.11 lbs,
- Manufacturer Warranty
- Service & Support: Limited warranty - advance parts replacement - 1 year - response time: 10 days,
- Environmental Parameters
- Min Operating Temperature: 32 °F,
- Max Operating Temperature: 104 °F,
- Humidity Range Operating: 5 - 85% (non-condensing),
- Min Storage Temperature: -40 °F,
- Max Storage Temperature: 158 °F,
- COO: BRAZIL / CHINA / MEXICO,
- TAA compliance: Yes,
