Pioneer TS-A301D4 12" 1600W Max Dual 4-Ohm Voice Coil DVC Car Audio Subwoofer
Limited time offer, ends 09/26 By Gibbys Electronic Supermarket
- Nominal Load Impedance: 4-ohm
+
+
Overview
Specs
Reviews
BRAND NEW
PIONEER TS-A301D4
CHAMPION Series 1600 Watts Max 12-Inch Dual 4 Ohm Voice Coil DVC Car Stereo Subwoofer
Key Features:
- Continuous Power Handling (RMS): 500 W
- Frequency Range: 20 Hz to 1.6 kHz
- Maximum Peak Power Handling - Watts: 1600 W
- Nominal Load Impedance: 4-ohm
- Sensitivity (1W/1m): 92 dB
- System-Type: Component
- Cut Out Dimensions: 11.125"
- Equivalent Compliance (VAS): 37.7
- Free Air Resonance (Fs): 38
- Linear Excursion (Xmax): 11.3
- Port Diameter: 3"
- Port Length: 6.5"
- Recommended Ported Box volume: 1.5 Cu Ft / 42.5 Liters
- Recommended Sealed Enclosure Volume: 1.25 Cu Ft / 35.4 Liters
- Subwoofer Mounting Depth: 6.125"
- Total Speaker "Q" (Qts): 0.73
- Basket Material: Steel
- Center Cap Material: Polypropylene
- Damper: Polycotton
- Drive Cone Material: Cellulose Fiber
- Installation Ring: ABS
- Magnet Material: Ferrite
- Magnet Weight: 90 oz
- Surround Material: Elastic Polymer / Reinforced Fiber
- Surround Type: Rolled
- Voice Coil Bobbin: Aluminum
- Voice Coil Type: Dual
- Voice Coil Wire: Copper
- Wire Terminals: Push Type
