8,000 media access control (MAC) addresses per system
Switching Method
Store and Forward
VLAN Support
Yes
Jumbo Frames
Yes
Buffer Memory
128KB
Details
Security
802.1x for authentication ACL filtering to permit or deny traffic based on MAC addresses
PoE
No
Stackable
Yes
SNMP
Yes
QoS
Yes
LACP
Yes
Layer
2
Port Mirroring
Yes
Module Support
Yes
LEDs
Unit: Power, Master, Stack ID Per Port: Link, Speed, Activity Per Gigabit Port: Link, Speed, Activity, Stack
Power Supply
Power
Power Consumption: 35.1W 100-240VAC/50-60 Hz universal input
Dimensions & Weight
Dimensions
17.3" x 10.1" x 1.7"
Weight
6.6 lbs.
Environmental
Temperature
0°C to 50°C (32°F to 122°F)
Humidity
90% Maximum, Non-condensing
Features
Features
Gigabit Stackable Smart Switches Enable Businesses to Grow with Ease Scalability and High Availability Advanced Security Advanced Quality of Service (QoS) 'Smart' Management Features
Administrative Switch Management: IEEE 8021.Q VLAN (128 groups, Static) IEEE 802.1p Class of Service (CoS) 4 hardware queues Port-based QoS IEEE 802.3ad Static or Dynamic Link Aggregation (LACP) IEEE 802.1D Spanning Tree Protocol SNMP v1, v2c, v3 RFC 1213 MIB II RFC 1643 Ethernet Interface MIB RFC 1493 Bridge MIB RFC 2131 DHCP client IEEE 802.1x (RADIUS) Access Control List (ACL) Layer 3 (DSCP) Quality of Service (QoS) TACACS+ Port-based security by locked MAC addresses Storm control for broadcast, multicast and unknown unicast packets Port-based ingress/egress rate limiting SNTP RMON group 1, 2, 3, 9 Private Enterprise MIB Port Mirroring Support Cable test Web-based configuration Configuration Backup/Restore Password Access Control Firmware upgradeable
Performance Specifications: Bandwidth: 48 Gbps Stacking bandwidth: 20 Gbps Network latency: Less than 20 microseconds for 64-byte frames in store-and-forward mode for 1000 Mbps to 1000 Mbps transmission Addressing: 48-bit MAC address Mean Time Between Failure (MTBF): 100,000 hours (~11 years)
For ProSafe Lifetime Warranty please see: http://www.netgear.com/warranty Power Adapter Warranty : 2 years
Additional Information
First Listed on Newegg
February 22, 2007
