The Monoprice 6 in 1 USB C Multiport 4K HDMI Adapter is an all in one video and data solution for USB C equipped laptops and computers with support for the DisplayPort 1.4 Alt Mode. You can extend your desktop with a second HDMI monitor with support for resolutions up to 4K@60Hz. It features both SD and microSD 3.0 card slots with support for the UHS I Speed Class and 104MBps read speeds. Each card slot is compatible with the MMC, SD, SDHC, and SDXC formats with capacities up to 2TB and is individually addressed, so they can be used at the same time.
Two USB 3.0 Type A ports and one Type C port provide data transfer speeds up to 5Gbps, so you can connect a variety of USB peripherals and devices. The USB C port supports up to 100W of Power Delivery (PD) and one of the Type A ports supports 5 VDC, 1.5A (7.5W) of charging power, so you can keep all your devices fully charged and ready for use. This adapter is compatible with USB C equipped Windows and macOS systems that support DisplayPort Alt Mode, as well as systems with a Thunderbolt 3 connection.
The Monoprice 6 in 1 USB C Multiport 4K HDMI Adapter allows you to get the most out of a single DisplayPort Alt Mode compatible USB C port. Connect an HDMI display, read data from SD and microSD cards, and connect one USB Type C and two USB Type A devices.
When connected to a host that supports the DisplayPort 1.4 Alt Mode, you can connect an HDMI display at resolutions up to 4K@60Hz. For older systems with support for DP1.2 Alt Mode, it supports resolutions up to 4K@30Hz.
Both SD and microSD card slots are included, each of which is individually addressed, so they can be used at the same time. They support the UHS I Speed Class (104MBps) and the SD, MMC, SDHC, and SDXC formats, which allow for capacities up to 2TB.
One USB 3.0 Type C and two Type A ports allow you to connect a variety of external peripherals, such as hard drives, flash drives, printers, and keyboard and mouse input devices. They support data transfer rates up to 5Gbps, which is more than 10x faster than the older USB 2.0 standard.
The USB C port supports up to 100W of USB Type C Power Delivery (PD) passthrough, allowing you to rapidly charge a laptop or other USB C compatible device. One of the Type A ports can provide 5 VDC, 1.5A (7.5W) of charging power for rapid charging of mobile devices.
The Monoprice 6 in 1 USB C Multiport 4K HDMI Adapter is a true Plug and Play device. Just plug it into a DisplayPort 1.4 Alt Mode compatible USB C port on your computer and use it right away. No external drivers or complicated configurations are required.
This adapter is compatible with computers running the Windows or macOS operating systems, as well as systems with a Thunderbolt 3 connection.
The adapter body measures just 4.6" x 1.3" x 0.5" and weighs only 2.0 ounces, making it easy to pack in your laptop bag, backpack, or purse. The attached USB-C cable is about 6.7" long.
| Products | |||
|---|---|---|---|
| Video Output | 1x HDMI | 1x HDMI | 1x HDMI |
| Maximum Video Resolution | 4K@60Hz | 4K@60Hz | 4K@60Hz |
| USB Ports | 1x Type C, 2x Type A | 1x Type C, 3x Type A | 1x Type C, 2x Type A |
| Power Delivery Passthrough | Up to 100W | Up to 100W | Up to 100W |
| USB Type A Charging Power | 1x 5 VDC, 1.5A (7.5W) | 1x 5 VDC, 1.5A (7.5W) | 1x 5 VDC, 1.5A (7.5W) |
| USB Data Transfer Rate | Up to 5Gbps | Up to 5Gbps | Up to 5Gbps |
| Ethernet Port | Gigabit | ||
| Card Slots | 1x SD, 1x microSD | 1x SD, 1x microSD | |
| Simultaneous Card Reading | N/A | ||
| SD Speed Class | UHS I (104MBps) | N/A | UHS I (104MBps) |
