Honeywell / Metrologic MK5145-31A38 Eclipse 5145 Barcode Scanner with USB Cable (Black)
- 1D Imager
- USB Cable Included
- 5 Year Warranty
+
+
Overview
Specs
Reviews (14)
Eclipse 5145 Single-Line Laser Scanner
Honeywell’s EclipseTM 5145 is a low cost laser-based alternative to CCD
scanners. Its compact form factor and high end feature set simplify its
use in a variety of applications at the press of a button.
Eclipse is a single-line, hand-held laser scanner. Equipped with Honeywell’s
patented CodeGate® technology, Eclipse can be used in a wide variety
of applications. CodeGate® technology allows the user to easily target
the desired bar code and complete data transmission with the press of a
single button. This makes Eclipse a perfect selection for menu scanning,
point-of-sale, document processing and inventory control.
With Honeywell’s state-of-the-art scanning technology, the Eclipse 5145
has a longer working range and a wider scan field than a typical CCD.
The width of the scan line grows as the scanner moves further away
from bar codes.
CodeSense® is a unique feature employed by Eclipse in the absence of
infrared object detection. It provides the user with a pulsing laser line for
bar code detection. When a bar code is detected, the laser line switches
to a constant state to allow for scanning via CodeGate®.
Features
-
CodeGate:
Zero in on desired code and complete data transmission with the push of a single button - ideal for menu scanning applications -
CodeSense:
Automatically wakes scanner from sleep mode when a bar code is detected -
Powerlink Cables:
Uses the same user-replaceable cables and power supplies as Voyager® and Orbit® -
Flash ROM:
Protects POS investment with free firmware updates via MetroSet2 software and standard PC -
OPOS and JPOS System Compatible:
Easily adaptable to any end-user system environment
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions (L x W x H) | 6.7 x 2.5 2.0" (169 x 63 x 51mm) |
| Weight | 3.5oz (100g) |
| Electrical | |
| Input Voltage | 5VDC ± 0.25V |
| Operating Power | 675mW (125mA @ 5V) |
| Host System Interfaces | USB, RS232, Keyboard Wedge, IBM 468xx (RS485) |
| Environmental | |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -40 to 140°F (-40 to 60°C) |
| Humidity | 5% to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 5' (1.5m) drops |
| Environmental | Sealing Sealed to resist airborne particulate contaminants |
| Light Levels | 4842 Lux |
| Scan Performance | |
| Scan Pattern | Single scan line |
| Scan Speed | 72 scan lines per second |
| Scan Angle | Horizontal: 50° |
| Print Contrast | 35% minimum reflectance difference |
| Pitch, Skew | 68 degrees, 52 degrees |
| Decode Capability | Reads standard 1D and GS1 DataBar symbologies |
| Warranty | Three-year factory warranty |
The Metrologic MS5145 Eclipse is a single-line, hand-held laser scanner. Equipped with Metrologic's CodeGate technology, the MS5145 Eclipse can be used in a wide variety of applications. CodeGate technology allows the user to easily target the desired barcode and complete the data transmission with a simple press of a button. This combination makes the Metrologic MS5145 Eclipse a perfect selection for menu scanning, point-of-sale, document processing and inventory control. The MS5145 also uses Metrologic's CodeSense technology that automatically switches from "pulse mode" to continuous beaming when a bar code is detected.
Standard features include Metrologic's PowerLink user-replaceable cables and power supply, allowing it to quickly connect to multiple system interface types including keyboard wedge, RS232, light pen emulation, IBM 468X/469X, stand-alone keyboard, and USB.
Standard features include Metrologic's PowerLink user-replaceable cables and power supply, allowing it to quickly connect to multiple system interface types including keyboard wedge, RS232, light pen emulation, IBM 468X/469X, stand-alone keyboard, and USB.
