Learn more about the GIGABYTE GV-N506TGAMING OC-8GD
Model| Brand | GIGABYTE |
|---|
| Series | Gaming |
|---|
| Model | GV-N506TGAMING OC-8GD |
|---|
| Part Number | GV-N506TGAMING OC-8GD |
|---|
Interface| Interface | PCI Express 5.0 x8 |
|---|
Chipset| Chipset Manufacturer | NVIDIA |
|---|
| GPU Series | NVIDIA GeForce RTX 50 Series |
|---|
| GPU | GeForce RTX 5060 Ti |
|---|
| Core Clock | 2647 MHz |
|---|
| CUDA Cores | 4608 Cores |
|---|
Memory| Effective Memory Clock | 28 GHz |
|---|
| Memory Size | 8GB |
|---|
| Memory Interface | 128-Bit |
|---|
| Memory Type | GDDR7 |
|---|
3D API| DirectX | DirectX 12 Ultimate |
|---|
| OpenGL | OpenGL 4.6 |
|---|
Ports| Multi-Monitor Support | 4 |
|---|
| HDMI | 1 x HDMI 2.1b |
|---|
| DisplayPort | 3 x DisplayPort 2.1b |
|---|
Details| Max Resolution | 7680 x 4320 |
|---|
| SLI Support | No |
|---|
| Cooler | Triple Fans |
|---|
| Thermal Design Power | 180W |
|---|
| Power Connector | 8-Pin |
|---|
| HDCP Ready | Yes |
|---|
Form Factor & Dimensions| Form Factor | ATX |
|---|
| Max GPU Length | 281 mm |
|---|
| Card Dimensions (L x H) | 281 x 119 x 40 mm |
|---|
| Slot Width | 2 Slots |
|---|
Additional Information| Date First Available | April 16, 2025 |
|---|
