FESTO MHP1-M5H-3/2G-M3-TC 197013 Air Solenoid Valve New

Valve function
3/2, closed, monostable
Lap
Underlap
Certificate issuing authority
UL MH19482
Actuation type
Electrical
Width
10 mm
Standard nominal flow rate
10 l/min
Pneumatic working port
M3
Operating voltage
12V DC
Operating pressure
0 bar ... 8 bar
Design
Poppet valve with return spring
Reset method
Mechanical spring
Degree of protection
IP40
Certification
c UL us - Recognized (OL)
Nominal width
0.65 mm
Width dimension
10 mm
Type code
MHP1
Exhaust air function
With flow control option
Sealing principle
Soft
Mounting position
Any
Manual override
Non-detenting
Type of control
Direct
Flow direction
Non-reversible
Symbol
00991308
Valve position ID
Label
Note on forced dynamization
Switching frequency at least once a week
Max. switching frequency
20 Hz
Switching time off
4 ms
On switching time
4 ms
Duty cycle
100%
Electrical power consumption
1 W
Coil characteristics
12 V DC: 1.0 W
Permissible voltage fluctuations
+/- 10 %
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Storage temperature
-20 °C ... 60 °C
Temperature of medium
-5 °C ... 40 °C
Ambient temperature
-5 °C ... 40 °C
Product weight
10 g
Electrical connection
Plug
