FESTO MHP1-M5H-2/2G-M3-PI 197052 Air Solenoid Valve New
- FESTO MHP1-M5H-2/2G-M3-PI 197052 Air Solenoid Valve New
+
+
Overview
Specs
Reviews
Valve function
2/2, closed, monostable
Lap
Underlap
Certificate issuing authority
UL MH19482
Actuation type
Electrical
Width
10 mm
Standard nominal flow rate
14 l/min
Pneumatic working port
M3
Operating voltage
12V DC
Operating pressure
-0.9 bar ... 2 bar
Design
Poppet valve with return spring
Reset method
Mechanical spring
Degree of protection
IP40
Certification
c UL us - Recognized (OL)
Nominal width
0.9 mm
Width dimension
10 mm
Type code
MHP1
Exhaust air function
Without flow control option
Sealing principle
Soft
Mounting position
Any
Manual override
Non-detenting
Type of control
Direct
Flow direction
Non-reversible
Symbol
00991398
Valve position ID
Label
Note on forced dynamization
Switching frequency at least once a week
Suitability for vacuum
yes
Max. switching frequency
20 Hz
Switching time off
5 ms
On switching time
4 ms
Duty cycle
100%
Electrical power consumption
1 W
Coil characteristics
12 V DC: 1.0 W
Permissible voltage fluctuations
+/- 10 %
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Storage temperature
-20 °C ... 60 °C
Temperature of medium
-5 °C ... 40 °C
Ambient temperature
-5 °C ... 40 °C
Product weight
10 g
2/2, closed, monostable
Lap
Underlap
Certificate issuing authority
UL MH19482
Actuation type
Electrical
Width
10 mm
Standard nominal flow rate
14 l/min
Pneumatic working port
M3
Operating voltage
12V DC
Operating pressure
-0.9 bar ... 2 bar
Design
Poppet valve with return spring
Reset method
Mechanical spring
Degree of protection
IP40
Certification
c UL us - Recognized (OL)
Nominal width
0.9 mm
Width dimension
10 mm
Type code
MHP1
Exhaust air function
Without flow control option
Sealing principle
Soft
Mounting position
Any
Manual override
Non-detenting
Type of control
Direct
Flow direction
Non-reversible
Symbol
00991398
Valve position ID
Label
Note on forced dynamization
Switching frequency at least once a week
Suitability for vacuum
yes
Max. switching frequency
20 Hz
Switching time off
5 ms
On switching time
4 ms
Duty cycle
100%
Electrical power consumption
1 W
Coil characteristics
12 V DC: 1.0 W
Permissible voltage fluctuations
+/- 10 %
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Storage temperature
-20 °C ... 60 °C
Temperature of medium
-5 °C ... 40 °C
Ambient temperature
-5 °C ... 40 °C
Product weight
10 g
