Cisco SG200-26FP 26-port Gigabit Full-PoE Smart Switch

Be the first to review this product...

Packet Buffer: 4MB Buffer Memory
PoE

Overview

Specs

Reviews

Model
Brand	Cisco Small Business
Model	SG200-26FP

Format & Standards
Standards	IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad LACP, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.1D (STP), IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879, RFC 896, RFC 826, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 922, RFC 920, RFC 950, RFC 951, RFC 1042, RFC 1071, RFC 1123, RFC 1141, RFC 1155, RFC 1350, RFC 1533, RFC 1541, RFC 1542, RFC 1624, RFC 1700, RFC 1867, RFC 2030, RFC 2616, RFC 2131, RFC 2132, RFC 3164, RFC 2618

Ports & Interface
Primary Ports	24 Gigabit Ethernet + 2 (RJ-45 + SFP) Gigabit Ethernet combo
Primary Port Speed	10/100/1000Mbps

Data Transmission
VLAN Support	Support for up to 256 VLANs simultaneously (out of 4096 VLAN IDs). 16 VLANs supported in SG200-08 and SG200-08P Port-based and 802.1Q tag-based VLANs Voice VLAN Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS

Details
Buffer Memory	Packet Buffer: 4MB
Protocols	TCP/IP
Security	IEEE 802.1X(Authenticator role): 802.1X: RADIUS authentication, MD5 hash Port security: Locks MAC addresses to ports, and limits the number of learned MAC addresses Storm control: Broadcast, multicast, and unknown unicast DoS prevention: DoS attack prevention
PoE	Yes
SNMP	SNMP versions 1, 2c, and 3 with support for traps, and SNMP version 3 user-based security model (USM)
QoS	Yes
LACP	Port grouping Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP) Up to 4 groups Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation
Port Mirroring	Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 4 source ports can be mirrored to one destination port. A single session is supported
Module Support	Yes
Cabling	Unshielded twisted pair (UTP) Category 5 or better for 10BASE-T/100BASE-TX; UTP Category 5 Ethernet or better for 1000BASE-T
LEDs	System, Link/Act, PoE, Speed
Button	Reset button
Power	100V-240V 50-60 Hz, internal, universal 100V-240V, 50V/3.6A, 12V/4, 50-60 Hz

Features
Features	High-speed desktop connectivity Highly secure wireless connectivity Unified communications Easy configuration and management Power over Ethernet (PoE) IP telephony support Networkwide automatic voice deployment IPv6 support An energy-efficient solution Switching capacity and forwarding rate: 38.69mpps/52Gbps Spanning Tree Protocol (STP) Standard 802.1d STP support Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]), enabled by default IGMP limits bandwidth-intensive multicast traffic to only the requesters; supports 256 multicast groups IPv6 host mode IPv6 over Ethernet Dual IPv6/IPv4 stack IPv6 neighbor and router discovery (ND) IPv6 stateless address auto-configuration Path maximum transmission unit (MTU) discovery Duplicate address detection (DAD) Internet Control Message Protocol (ICMP) version 6 IPv6 over IPv4 network with Intra-Site Automatic Tunnel Addressing Protocol (ISATAP) support IPv6 QoS: Prioritize IPv6 packets in hardware Web user interface Built-in switch configuration utility for easy browser-based device configuration (HTTP). Supports configuration, system dashboard, system maintenance, and monitoring

Dimensions & Weight
Dimensions	1.73" x 17.35" x 10.10
Weight	8.42 lbs.

Group
Model	SG200-26FP-NA

Additional Information
First Listed on Newegg	December 13, 2013

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): Lifetime
Limited Warranty period (labor): Lifetime
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.ca's Standard Return Policy.
Read full return policy for details.
