CEM SMD-100 Smart Electronic Components Tester 6000 Counts LCD Display
- CEM SMD-100 Smart Electronic Components Tester 6000 Counts LCD Display
+
+
Overview
Specs
Reviews
CEM SMD-100 Smart Electronic Components Tester 6000 Counts LCD Display
Notice:
The standard package don't include batteries.Because,the international air shipping forbid to ship liquid,powder and batteries,we can not put them in the package box.Hope you can understand buy them in your local store or supermarket.
At the same time, please forgive us that we are unable to provide the English user manual. If you need it, please contact the customer service after purchase.
Thanks for your support!
Features
Automatic DCV or ACV selection, Capacitance, Resistance, Continuity and diode selection
6000 counts LCD display
Auto scan DC/AC Voltage, resistance, capacitance, diode and continuity
Data Hold/MAX/MIN recording mode
Auto Power Off
Wide capacitance range
Diode Check & Continuity Test
Size (H x W x D): 184mm x 37mm x 23mm
Weight: 76g
Specifications
Function Range Basic Accuracy
Voltage DC 600mV/6V/60V/600V ±0.8%
Voltage AC 600mV/6V/60V/600V ±1.0%
Resistance (?) 600/60k/60k/600k/6M/60M ±1.0%
Capacitance (F) 6n/60n/600n/6µ/60µ/600µ/6m/60m ±3.5%
Diode check Open voltage 2.8Vdc, test current 1mA
Continuity test Threshold 35 ?
Notice:
The standard package don't include batteries.Because,the international air shipping forbid to ship liquid,powder and batteries,we can not put them in the package box.Hope you can understand buy them in your local store or supermarket.
At the same time, please forgive us that we are unable to provide the English user manual. If you need it, please contact the customer service after purchase.
Thanks for your support!
Features
Automatic DCV or ACV selection, Capacitance, Resistance, Continuity and diode selection
6000 counts LCD display
Auto scan DC/AC Voltage, resistance, capacitance, diode and continuity
Data Hold/MAX/MIN recording mode
Auto Power Off
Wide capacitance range
Diode Check & Continuity Test
Size (H x W x D): 184mm x 37mm x 23mm
Weight: 76g
Specifications
Function Range Basic Accuracy
Voltage DC 600mV/6V/60V/600V ±0.8%
Voltage AC 600mV/6V/60V/600V ±1.0%
Resistance (?) 600/60k/60k/600k/6M/60M ±1.0%
Capacitance (F) 6n/60n/600n/6µ/60µ/600µ/6m/60m ±3.5%
Diode check Open voltage 2.8Vdc, test current 1mA
Continuity test Threshold 35 ?
