BIOSTAR TP45E Combo 6.X LGA 775 Intel P45 ATX Intel Motherboard
- Intel P45
- Core 2 Quad / Duo / Pentium Dual-Core / Celeron
- Support Dual Channel DDR2 667/800/1066(OC) MHz Support Dual Channel DDR3 800/1066/1333(OC) MHz
Specs
Reviews (8)
Learn more about the Biostar TP45E Combo 6.X
| Brand | BIOSTAR |
|---|---|
| Model | TP45E Combo 6.X |
| CPU Socket Type | LGA 775 |
|---|---|
| CPU Type | Core 2 Quad / Duo / Pentium Dual-Core / Celeron |
| FSB | 800/1066/1333/1600(OC)MHz |
| Chipset | Intel P45 |
|---|---|
| South Bridge | Intel ICH10 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | Support Dual Channel DDR2 667/800/1066(OC) MHz Support Dual Channel DDR3 800/1066/1333(OC) MHz |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 3 x PCI Slots |
| PATA | 1 x ATA100 2 Dev. Max |
|---|
| Audio Chipset | Realtek ALC662 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8111DL |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 2 x PS/2 / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| USB 1.1/2.0 | 6 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 8.66" |
| Power Pin | 24 Pin |
| First Listed on Newegg | June 22, 2009 |
|---|
