Multiple management VLAN assignment 802.1Q Tagged VLAN MAC-based VLAN Surveillance VLAN Voice VLAN Up to 256 VLAN groups, ID Range 1-4094
Jumbo Frames
10KB
Buffer Memory
512KB
Details
Security
802.1X port-based authentication (Local user database, RADIUS, Guest VLAN) DHCP Snooping / Option 82 Loopback detection Denial of Service (DoS) prevention Storm control (broadcast, unknown multicast, unknown unicast, min: 16Kbps) Head-of-line (HoL) blocking prevention IP Source Guard / IP-MAC-Port-VLAN binding Protected ports Port Security/MAC address learning restriction (Up to 255 entries)
QoS
802.1p Class of Service (CoS) DSCP (Differentiated Services Code Point) Bandwidth limit per port Queue Scheduling: strict priority (SP), weighted round robin (WRR)
Power Supply
Power
Input: 100 - 240V AC, 50/60Hz, internal power supply Max. consumption: 10W (No PoE load)
Dimensions & Weight
Dimensions
12.90" x 9.10" x 1.75"
Weight
4.98 lbs.
Environmental
Temperature
Operating Temperature: 0° - 40° C (32° - 104° F)
Humidity
Operating Humidity: Max. 90% non-condensing
Additional Information
Date First Available
January 23, 2025
