Fractal Design Define R5 FD-CA-DEF-R5-TI Titanium ATX / Micro ATX Mid Tower Computer Case

Be the first to review this product...

Steel ATX Mid Tower
Optimally designed for silent computing with high density noise-reducing material throughout
Patent pending ModuVent design, allowing the user to either have optimal silence or optimal airflow
Supports up to 4 radiators (1 X 420/360/280/240mm, 1 X 360/280/240mm, 1 X 240/120mm & 1 X 140/120mm)
Newly configured front door with dual side mounting
Fully removable 5.25" drive cage
Integrated 3 Speed Fan Controller
Removable Dust Filters

Overview

Specs

Reviews

The Fractal Design Define R5 is the next evolution in the widely popular Define Series. Packed with intelligently designed enthusiast-oriented features delivering a silent case with powerful and expansive air and liquid cooling support, presented in a stunning Scandinavian inspired construction.

The Define R5 case reaches the highest level of silent computing through strategically placed dense sound-absorbing material, ModuVent™ fan vent covers and finely tuned Dynamic Series fans.

The Define R5 was designed with configurability in mind, accommodating up to 8 hard drives and all modern graphics card. Should you wish to expand your system with water cooling components or more fans the layout can easily be configured to meet your demand.

Model
Brand	Fractal Design
Series	Define R5
Model	FD-CA-DEF-R5-TI

Details
Type	ATX / Micro ATX Mid Tower
Color	Titanium
With Power Supply	No
Power Supply Mounted	Bottom
Motherboard Compatibility	Micro ATX / ATX / Mini-ITX
Side Panel Window	No

Expansion
External 5.25" Drive Bays	2
External 3.5" Drive Bays	No
Internal 3.5" Drive Bays	8 - 3.5" HDD positions (can also accommodate 2.5" units)
External 2.5" Drive Bays	No
Internal 2.5" Drive Bays	2 - 2.5" dedicated SSD unit positions
Expansion Slots	7

Front Panel Ports
Front Ports	2 x USB 3.0 / 2 x USB 2.0 / Audio

Cooling System
140mm Fans	Front: 2 - 120/140mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM speed) Rear: 1 - 120/140mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM speed) Top: 3 - 120/140mm fan (not included) Bottom: 2 - 120/140mm fan (not included) Side: 1 - 120/140mm fan (not included)

Dimensions & Weight
Max GPU Length	440 mm
Max CPU Cooler Height	180 mm
Dimensions	18.19" x 9.13" x 20.91" with feet / screws / protrusions 17.76" x 9.13" x 20.51"
Weight	22.69 lbs.

Additional Info
Features	Optimally designed for silent computing with high density noise-reducing material throughout the case for maximum sound absorption, while not compromising on airflow and cooling capabilities. Extensive water cooling support for a case of this size; housing radiators up to 420mm in the top and 360mm in the front. Equipped with new tool-less ModuVent fan slot covers allowing the user to install more fans if desired or keep fan slots covered to maximize sound absorption. Including two Fractal Design Dynamic GP14 140mm fans developed for superlative airflow while still maintaining low noise levels. Maintaining a dust-free interior with the help of dust filters that cover front and bottom air intakes that are easy to access from the front on the case. Newly configured front door with dual side mounting to better fit your work space. Highlighting 2 dedicated SSD mounts cleanly placed behind the motherboard tray that feature innovative new brackets delivering a tool-free installation and removal. The HDD cage system holds up to eight 3.5" or 2.5" drives and is more adaptable than ever, allowing the user to modify the case layout according to personal preference with more places to relocate the cages. The ODD cage can easily be removed to gain additional interior space; the area can be freed up to allow for increased airflow, to provide a new place for HDD cage mounting or to make more room for water cooling components. Sturdy metal HDD trays provide excellent dampening features for the hard drives while providing better airflow through the cage with an updated, more open design. The new and innovative Quick Release System on the left side of the case provides secure mounting of the left side panel, yet grants quick and easy access to the system. Three-speed fan controller is strategically integrated in the front panel and supports up to 3 fans. Define R5 model is available with window side panel.

Additional Information
First Listed on Newegg	January 10, 2018
