SUPERMICRO MBD-X10SDV-4C-TLN2F-O Intel Xeon D-1521 Mini ITX Server Motherboard

In stock.
Ships from United States.
Fees for brokerage and duty included in price.
  • Intel Xeon D-1541
  • Intel Xeon D-1521
  • Intel Xeon processor D-1521
  • Up to 128GB ECC RDIMM DDR4 2133 MHz or 64GB ECC / non-ECC UDIMM in 4 sockets
  • 6 x SATA3 (6 Gbps) ports via SoC
  • 2 x USB 3.0 ports (rear) 4 x USB 2.0 ports (via headers)
  • 12V DC input and ATX Power Source
Overview
Specs
Reviews
X10SDV-4C-TLN2F

SUPERMICRO MBD-X10SDV-4C-TLN2F-O Mini ITX Server Motherboard

Features

X10SDV-4C-TLN2F
  • Intel® Xeon® processor D-1521, Single socket FCBGA 1667; 4-Core, 8 Threads, 45W
  • System on Chip
  • Up to 128GB ECC RDIMM DDR4 2133MHz or 64GB ECC/non-ECC UDIMM in 4 sockets
  • Expansion slot: 1x PCIe 3.0 x16 M.2 PCIe 3.0 x4, M Key 2242/2280
  • Dual 10GbE LAN
  • 6x SATA3 (6Gbps) ports via SoC
  • 2x USB 3.0 ports (rear) 4x USB 2.0 ports (via headers)
  • 1x SuperDOM, 1x COM, TPM 1.2 header, GPIO and SMbus headers
  • 12V DC input and ATX Power Source

Specifications

Product SKUs
Motherboard X10SDV-4C-TLN2F (Bulk Pack)
Physical Stats
Form Factor Mini-ITX
Dimensions 6.7" x 6.7", (17cm x 17cm)
Processor/Cache
CPU
  • Intel® Xeon® processor D-1521
  • FCBGA 1667
  • CPU TDP support 45W, 2.2-2.6GHz, 12MB, 4 Cores, 8 Threads
System Memory
Memory Capacity
  • 4x DDR4 DIMM sockets
  • Supports up to 128GB DDR4 ECC RDIMM
  • Supports up to 64GB DDR4 ECC/non-ECC UDIMM
Memory Type 2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM
DIMM Sizes 32GB, 16GB, 8GB, 4GB
Memory Voltage 1.2V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset System on Chip
SATA System on Chip
Network Controllers
  • Dual LAN via SoC 10GBase-T
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • 1x Realtek RTL8201N PHY (dedicated IPMI)
IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Video Aspeed AST2400
TPM TPM header
Input / Output
SATA 6x SATA3 (6Gbps) ports
LAN
  • 2x RJ45 10GBase-T ports
  • 1x RJ45 Dedicated IPMI LAN port
USB
  • 2x USB 3.0 ports (rear)
  • 4x USB 2.0 ports (via headers)
Video 1x VGA port
Serial Port / Header 1x COM port (header)
DOM 1x SuperDOM (Disk on Module) power connector

Whats in the Box

X10SDV-4C-TLN2F

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
  • Read full details

Return Policies

    We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1, 2021 and December 24, 2021 you will have until January 31, 2022 to return your product. There's nothing additional that you have to do!
  • Return for refund until: January 31, 2022
  • Return for replacement until: January 31, 2022
  • This item is covered by Newegg.ca's Extended Holiday Return Policy
